Aluminum Electrolytic Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Polarization | Ratings | Applications | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MAL215876123E3CAP ALUM 12000UF 20% 25V SNAP TH |
0 |
|
Datasheet |
158 PUL-SI | Bulk | Active | 12000 µF | ±20% | 25 V | 53mOhm @ 100Hz | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 4.19 A @ 100 Hz | - | 46 mOhms | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
SLPX182M250H9P3CAP ALUM 1800UF 20% 250V SNAP TH |
0 |
|
Datasheet |
SLPX | Bulk | Active | 1800 µF | ±20% | 250 V | 111mOhm @ 120Hz | 3000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 4.54 A @ 120 Hz | 6.67 A @ 20 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.969" (50.00mm) | - | Through Hole | |
|
ALF40G332EE100CAP ALUM 3300UF 20% 100V PRESS |
0 |
|
Datasheet |
ALF40 | Bulk | Active | 3300 µF | ±20% | 100 V | 78mOhm @ 100Hz | 9000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 5.59 A @ 100 Hz | 5.95 A @ 10 kHz | 66 mOhms | 0.984" (25.00mm) | 1.575" Dia (40.00mm) | 1.850" (47.00mm) | - | Through Hole, Press-Fit | |
|
ALS80H133DA040CAP ALUM 13000UF 20% 40V SCREW |
0 |
|
Datasheet |
ALS80 | Bulk | Active | 13000 µF | ±20% | 40 V | 49mOhm @ 100Hz | 6000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 8 A @ 100 Hz | 10.4 A @ 10 kHz | 41 mOhms | 0.504" (12.80mm) | 1.417" Dia (36.00mm) | 2.126" (54.00mm) | - | Chassis Mount | |
|
MAL215962681E3CAP ALUM 680UF 20% 200V SNAP TH |
0 |
|
Datasheet |
159 PUL-SI | Bulk | Active | 680 µF | ±20% | 200 V | 350mOhm @ 100Hz | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.44 A @ 120 Hz | - | 340 mOhms | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.063" (27.00mm) | - | Through Hole | |
|
|
MAL215982681E3CAP ALUM 680UF 20% 200V SNAP TH |
0 |
|
Datasheet |
159 PUL-SI | Bulk | Active | 680 µF | ±20% | 200 V | 350mOhm @ 100Hz | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.44 A @ 120 Hz | - | 340 mOhms | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.063" (27.00mm) | - | Through Hole | |
|
MAL225723122E3CAP ALUM 1200UF 20% 250V SNAP TH |
0 |
|
- |
257 PRM-SI | Box | Active | 1200 µF | ±20% | 250 V | 150mOhm @ 100Hz | 5000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 3.06 A @ 100 Hz | 4.284 A @ 10 kHz | 110 mOhms | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
|
MAL225713122E3CAP ALUM 1200UF 20% 250V SNAP TH |
0 |
|
- |
257 PRM-SI | Box | Active | 1200 µF | ±20% | 250 V | 150mOhm @ 100Hz | 5000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 3.06 A @ 100 Hz | 4.284 A @ 10 kHz | 110 mOhms | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
MAL225939181E3CAP ALUM 180UF 20% 500V SNAP TH |
0 |
|
- |
259 PHM-SI | Box | Active | 180 µF | ±20% | 500 V | 770mOhm @ 100Hz | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.44 A @ 100 Hz | 2.16 A @ 10 kHz | 590 mOhms | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
|
MAL225979181E3CAP ALUM 180UF 20% 500V SNAP TH |
0 |
|
- |
259 PHM-SI | Box | Active | 180 µF | ±20% | 500 V | 770mOhm @ 100Hz | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.44 A @ 100 Hz | 2.16 A @ 10 kHz | 590 mOhms | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
PEH536YDG3330M2CAP ALUM SNAP-IN 105C |
0 |
|
Datasheet |
PEH536 | Box | Active | 330 µF | ±20% | 450 V | 220mOhm @ 100Hz | 4600 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.7 A @ 100 Hz | 11.9 A @ 20 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
LGR2W181MELB45CAP ALUM 180UF 20% 450V SNAP TH |
17 |
|
Datasheet |
LGR | Bulk | Active | 180 µF | ±20% | 450 V | - | 10000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 870 mA @ 120 Hz | 1.2441 A @ 50 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.850" (47.00mm) | - | Through Hole | |
|
400USC270MEFCSN30X30CAP ALUM 270UF 20% 400V SNAP TH |
0 |
|
Datasheet |
USC | Bulk | Not For New Designs | 270 µF | ±20% | 400 V | - | 3000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 1.82 A @ 120 Hz | 2.548 A @ 10 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
B43541B8187M080CAP ALUM 180UF 20% 600V SNAP TH |
0 |
|
Datasheet |
B43541 | Tray | Active | 180 µF | ±20% | 600 V | 650mOhm @ 100Hz | 5000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 1.71 A @ 100 Hz | - | 1.01 Ohms | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.661" (42.20mm) | - | Through Hole | |
|
|
ALF40C561DH350CAP ALUM 560UF 20% 350V PRESS |
0 |
|
Datasheet |
ALF40 | Bulk | Active | 560 µF | ±20% | 350 V | 224mOhm @ 100Hz | 8000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3.11 A @ 100 Hz | 5.7 A @ 10 kHz | 155 mOhms | 0.886" (22.50mm) | 1.378" Dia (35.00mm) | 2.441" (62.00mm) | - | Through Hole, Press-Fit | |
|
|
PEH532YDE3390M2CAP ALUM SNAP-IN 105C |
0 |
|
Datasheet |
PEH532 | Box | Active | 390 µF | ±20% | 450 V | 240mOhm @ 100Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.6 A @ 100 Hz | 4.5 A @ 20 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
ALS71H332DA100CAP ALUM 3300UF 20% 100V SCREW |
0 |
|
Datasheet |
ALS71 | Bulk | Active | 3300 µF | ±20% | 100 V | 99mOhm @ 100Hz | 11000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 6.6 A @ 100 Hz | 9.3 A @ 10 kHz | 81 mOhms | 0.504" (12.80mm) | 1.417" Dia (36.00mm) | 2.126" (54.00mm) | - | Chassis Mount | |
|
|
475MXT330MEFCSN30X30CAP ALUM 330UF 20% 475V SNAP TH |
0 |
|
Datasheet |
MXT | Bulk | Active | 330 µF | ±20% | 475 V | - | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.48 A @ 120 Hz | 2.072 A @ 10 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
|
ALF40G822ED063CAP ALUM 8200UF 20% 63V PRESS |
0 |
|
Datasheet |
ALF40 | Bulk | Active | 8200 µF | ±20% | 63 V | 72mOhm @ 100Hz | 9000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 5.01 A @ 100 Hz | 5.12 A @ 10 kHz | 64 mOhms | 0.984" (25.00mm) | 1.575" Dia (40.00mm) | 1.654" (42.00mm) | - | Through Hole, Press-Fit | |
|
380LX821M450A082CAP ALUM 820UF 20% 450V SNAP TH |
0 |
|
Datasheet |
380LX | Bulk | Active | 820 µF | ±20% | 450 V | 243mOhm @ 120Hz | 3000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 3.8 A @ 120 Hz | - | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 3.228" (82.00mm) | - | Through Hole |
