Aluminum Electrolytic Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Polarization | Ratings | Applications | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MAL210689683E3CAP ALUM 68000UF 100V SCREW CHAS |
0 |
|
Datasheet |
106 PED-ST | Bulk | Active | 68000 µF | -10%, +30% | 100 V | 5mOhm @ 100Hz | 20000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 50 A @ 100 Hz | - | 5 mOhms | 1.252" (31.80mm) | 3.543" Dia (90.00mm) | 8.835" (224.40mm) | - | Chassis Mount | |
|
CGS772T450X8LCAP ALUM 7700UF 450V SCREW CHAS |
0 |
|
Datasheet |
CGS | Bulk | Active | 7700 µF | -10%, +50% | 450 V | 20mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 16.7 A @ 120 Hz | 25.05 A @ 10 kHz | - | - | 3.000" Dia (76.20mm) | 8.625" (219.08mm) | - | Chassis Mount | |
|
MAL250077153E3CAP ALUM 15000UF 20% 450V SCREW |
0 |
|
- |
500 PGP-ST | Box | Active | 15000 µF | ±20% | 450 V | 11mOhm @ 100Hz | 5000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 25.8 A @ 100 Hz | 38.7 A @ 10 kHz | 10 mOhms | 1.252" (31.80mm) | 3.520" Dia (89.40mm) | 8.626" (219.10mm) | - | Chassis Mount | |
|
MAL250037153E3CAP ALUM 15000UF 20% 450V SCREW |
0 |
|
- |
500 PGP-ST | Box | Active | 15000 µF | ±20% | 450 V | 11mOhm @ 100Hz | 5000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 25.8 A @ 100 Hz | 38.7 A @ 10 kHz | 10 mOhms | 1.252" (31.80mm) | 3.520" Dia (89.40mm) | 8.626" (219.10mm) | - | Chassis Mount | |
|
M39018/06-0124MCAP ALUM SCREW |
0 |
|
- |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
|
M39018/04-2083MALUM-SCREW TERMINAL |
0 |
|
- |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
MAL250139123E3CAP ALUM 12000UF 20% 500V SCREW |
0 |
|
Datasheet |
501 PGM-ST | Box | Active | 12000 µF | ±20% | 500 V | 22mOhm @ 100Hz | 5000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 26.4 A @ 100 Hz | 39.6 A @ 10 kHz | 19 mOhms | 1.252" (31.80mm) | 3.520" Dia (89.40mm) | 7.602" (193.10mm) | - | Chassis Mount | |
|
|
MAL250179123E3CAP ALUM 12000UF 20% 500V SCREW |
0 |
|
Datasheet |
501 PGM-ST | Box | Active | 12000 µF | ±20% | 500 V | 22mOhm @ 100Hz | 5000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 26.4 A @ 100 Hz | 39.6 A @ 10 kHz | 19 mOhms | 1.252" (31.80mm) | 3.520" Dia (89.40mm) | 7.602" (193.10mm) | - | Chassis Mount | |
|
|
B43456A4189M000CAP ALUM 18000UF 20% 350V SCREW |
0 |
|
Datasheet |
B43456 | Bulk | Obsolete | 18000 µF | ±20% | 350 V | 5mOhm @ 100Hz | 12000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 38 A @ 100 Hz | - | 7 mOhms | 1.248" (31.70mm) | 3.583" Dia (91.00mm) | 8.740" (222.00mm) | - | Chassis Mount | |
|
MAL210149154E3CAP ALUM 150000UF 20% 100V SCREW |
0 |
|
Datasheet |
101 PHR-ST | Bulk | Active | 150000 µF | ±20% | 100 V | 5mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 49.1 A @ 100 Hz | - | 5 mOhms | 1.252" (31.80mm) | 3.543" Dia (90.00mm) | 8.795" (223.40mm) | - | Chassis Mount | |
|
|
MAL210189154E3CAP ALUM 150000UF 20% 100V SCREW |
0 |
|
Datasheet |
101 PHR-ST | Bulk | Active | 150000 µF | ±20% | 100 V | 5mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 49.1 A @ 100 Hz | - | 5 mOhms | 1.252" (31.80mm) | 3.543" Dia (90.00mm) | 8.795" (223.40mm) | - | Chassis Mount | |
|
|
CGS153T300X8LCAP ALUM 15000UF 300V SCREW CHAS |
0 |
|
Datasheet |
CGS | Bulk | Active | 15000 µF | -10%, +50% | 300 V | 15mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 19.8 A @ 120 Hz | 29.7 A @ 10 kHz | - | - | 3.000" Dia (76.20mm) | 8.625" (219.08mm) | - | Chassis Mount | |
|
CGH772T450X8LCAP ALUM 7700UF 450V SCREW CHAS |
0 |
|
Datasheet |
CGH | Bulk | Active | 7700 µF | -10%, +50% | 450 V | 17.3mOhm @ 120Hz | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 18.2 A @ 120 Hz | 22.386 A @ 10 kHz | - | - | 3.000" Dia (76.20mm) | 8.625" (219.08mm) | - | Chassis Mount | |
|
B43458A9159M000CAP ALUM 15000UF 20% 400V SCREW |
0 |
|
Datasheet |
B43458 | Bulk | Obsolete | 15000 µF | ±20% | 400 V | 6mOhm @ 100Hz | 12000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 35 A @ 100 Hz | - | 11 mOhms | 1.248" (31.70mm) | 3.583" Dia (91.00mm) | 8.740" (222.00mm) | - | Chassis Mount | |
|
|
MAL210148334E3CAP ALUM 330000UF 20% 63V SCREW |
0 |
|
Datasheet |
101 PHR-ST | Bulk | Active | 330000 µF | ±20% | 63 V | 5mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 42.9 A @ 100 Hz | - | 5 mOhms | 1.252" (31.80mm) | 3.543" Dia (90.00mm) | 8.795" (223.40mm) | - | Chassis Mount | |
|
|
MAL210188334E3CAP ALUM 330000UF 20% 63V SCREW |
0 |
|
Datasheet |
101 PHR-ST | Bulk | Active | 330000 µF | ±20% | 63 V | 5mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 42.9 A @ 100 Hz | - | 5 mOhms | 1.252" (31.80mm) | 3.543" Dia (90.00mm) | 8.795" (223.40mm) | - | Chassis Mount | |
|
|
M39018/04-2038MCAP ALUM SCREW |
0 |
|
- |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
|
M39018/04-2040MCAP ALUM SCREW |
0 |
|
- |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
|
M39018/04-2102MCAP ALUM SCREW |
0 |
|
- |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
|
M39018/04-2105MCAP ALUM SCREW |
0 |
|
- |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
