Aluminum Electrolytic Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Polarization | Ratings | Applications | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SMG25VB471M10X12LLCAP ALUM 470UF 20% 25V RADIAL TH |
0 |
|
- |
SMG | Bulk | Obsolete | 470 µF | ±20% | 25 V | 564mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 545 mA @ 120 Hz | 817.5 mA @ 100 kHz | - | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 0.492" (12.50mm) | - | Through Hole | |
|
SMG25VB102M10X20LLCAP ALUM 1000UF 20% 25V RADIAL |
0 |
|
- |
SMG | Bulk | Obsolete | 1000 µF | ±20% | 25 V | 265mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 955 mA @ 120 Hz | 1.4325 A @ 100 kHz | - | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 0.787" (20.00mm) | - | Through Hole | |
|
SMG25VB222M12X25LLCAP ALUM 2200UF 20% 25V RADIAL |
0 |
|
- |
SMG | Bulk | Obsolete | 2200 µF | ±20% | 25 V | 136mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 1.54 A @ 120 Hz | 1.6632 A @ 100 kHz | - | 0.197" (5.00mm) | 0.492" Dia (12.50mm) | 0.984" (25.00mm) | - | Through Hole | |
|
SMG25VB332M16X25LLCAP ALUM 3300UF 20% 25V RADIAL |
0 |
|
- |
SMG | Bulk | Obsolete | 3300 µF | ±20% | 25 V | 100mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 1.975 A @ 120 Hz | 2.133 A @ 100 kHz | - | 0.295" (7.50mm) | 0.630" Dia (16.00mm) | 0.984" (25.00mm) | - | Through Hole | |
|
SMG25VB332M20SLLCAP ALUM 3300UF 20% 25V RADIAL |
0 |
|
- |
SMG | Bulk | Obsolete | 3300 µF | ±20% | 25 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 1.85 A @ 120 Hz | 1.998 A @ 100 kHz | - | 0.394" (10.00mm) | 0.787" Dia (20.00mm) | 0.787" (20.00mm) | - | Through Hole | |
|
|
SMG25VB472M16X31LLCAP ALUM 4700UF 20% 25V RADIAL |
0 |
|
- |
SMG | Bulk | Obsolete | 4700 µF | ±20% | 25 V | 78mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 2.42 A @ 120 Hz | 2.6136 A @ 100 kHz | - | 0.295" (7.50mm) | 0.630" Dia (16.00mm) | 1.240" (31.50mm) | - | Through Hole | |
|
SMG25VB682M18X35LLCAP ALUM 6800UF 20% 25V RADIAL |
0 |
|
- |
SMG | Bulk | Obsolete | 6800 µF | ±20% | 25 V | 63mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 2.88 A @ 120 Hz | 3.1104 A @ 100 kHz | - | 0.295" (7.50mm) | 0.709" Dia (18.00mm) | 1.398" (35.50mm) | - | Through Hole | |
|
SMG35VB4R7M5X11LLCAP ALUM 4.7UF 20% 35V RADIAL TH |
0 |
|
- |
SMG | Bulk | Obsolete | 4.7 µF | ±20% | 35 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 41 mA @ 120 Hz | 102.5 mA @ 100 kHz | - | 0.079" (2.00mm) | 0.197" Dia (5.00mm) | 0.433" (11.00mm) | - | Through Hole | |
|
|
SMG35VB10RM5X11LLCAP ALUM 10UF 20% 35V RADIAL TH |
0 |
|
- |
SMG | Bulk | Obsolete | 10 µF | ±20% | 35 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 59 mA @ 120 Hz | 106.2 mA @ 100 kHz | - | 0.079" (2.00mm) | 0.197" Dia (5.00mm) | 0.433" (11.00mm) | - | Through Hole | |
|
|
SMG35VB22RM5X11LLCAP ALUM 22UF 20% 35V RADIAL TH |
0 |
|
- |
SMG | Bulk | Obsolete | 22 µF | ±20% | 35 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 88 mA @ 120 Hz | 158.4 mA @ 100 kHz | - | 0.079" (2.00mm) | 0.197" Dia (5.00mm) | 0.433" (11.00mm) | - | Through Hole | |
|
|
SMG35VB33RM5X11LLCAP ALUM 33UF 20% 35V RADIAL TH |
0 |
|
- |
SMG | Bulk | Obsolete | 33 µF | ±20% | 35 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 108 mA @ 120 Hz | 194.4 mA @ 100 kHz | - | 0.079" (2.00mm) | 0.197" Dia (5.00mm) | 0.433" (11.00mm) | - | Through Hole | |
|
|
SMG35VB47RM5X11LLCAP ALUM 47UF 20% 35V RADIAL TH |
0 |
|
- |
SMG | Bulk | Obsolete | 47 µF | ±20% | 35 V | 4.937Ohm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 130 mA @ 120 Hz | 234 mA @ 100 kHz | - | 0.079" (2.00mm) | 0.197" Dia (5.00mm) | 0.433" (11.00mm) | - | Through Hole | |
|
SMG35VB101M6X11LLCAP ALUM 100UF 20% 35V RADIAL TH |
0 |
|
- |
SMG | Bulk | Obsolete | 100 µF | ±20% | 35 V | 2.321Ohm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 210 mA @ 120 Hz | 315 mA @ 100 kHz | - | 0.098" (2.50mm) | 0.248" Dia (6.30mm) | 0.433" (11.00mm) | - | Through Hole | |
|
SMG35VB221M8X11LLCAP ALUM 220UF 20% 35V RADIAL TH |
0 |
|
- |
SMG | Bulk | Obsolete | 220 µF | ±20% | 35 V | 1.055Ohm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 385 mA @ 120 Hz | 577.5 mA @ 100 kHz | - | 0.138" (3.50mm) | 0.315" Dia (8.00mm) | 0.453" (11.50mm) | - | Through Hole | |
|
|
SMG35VB331M10X12LLCAP ALUM 330UF 20% 35V RADIAL TH |
0 |
|
- |
SMG | Bulk | Obsolete | 330 µF | ±20% | 35 V | 703mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 490 mA @ 120 Hz | 735 mA @ 100 kHz | - | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 0.492" (12.50mm) | - | Through Hole | |
|
SMG35VB471M10X16LLCAP ALUM 470UF 20% 35V RADIAL TH |
0 |
|
- |
SMG | Bulk | Obsolete | 470 µF | ±20% | 35 V | 494mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 645 mA @ 120 Hz | 967.5 mA @ 100 kHz | - | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 0.630" (16.00mm) | - | Through Hole | |
|
|
SMG35VB102M12X20LLCAP ALUM 1000UF 20% 35V RADIAL |
0 |
|
- |
SMG | Bulk | Obsolete | 1000 µF | ±20% | 35 V | 232mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 1.145 A @ 120 Hz | 1.7175 A @ 100 kHz | - | 0.197" (5.00mm) | 0.492" Dia (12.50mm) | 0.787" (20.00mm) | - | Through Hole | |
|
|
SMG35VB222M16X25LLCAP ALUM 2200UF 20% 35V RADIAL |
0 |
|
- |
SMG | Bulk | Obsolete | 2200 µF | ±20% | 35 V | 121mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 1.785 A @ 120 Hz | 1.9278 A @ 100 kHz | - | 0.295" (7.50mm) | 0.630" Dia (16.00mm) | 0.984" (25.00mm) | - | Through Hole | |
|
|
SMG35VB472M18X35LLCAP ALUM 4700UF 20% 35V RADIAL |
0 |
|
- |
SMG | Bulk | Obsolete | 4700 µF | ±20% | 35 V | 71mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 2.7 A @ 120 Hz | 2.16 A @ 100 kHz | - | 0.295" (7.50mm) | 0.709" Dia (18.00mm) | 1.398" (35.50mm) | - | Through Hole | |
|
SMG35VB472M22BLLCAP ALUM 4700UF 20% 35V RADIAL |
0 |
|
- |
SMG | Bulk | Obsolete | 4700 µF | ±20% | 35 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 2.38 A @ 120 Hz | 2.5704 A @ 100 kHz | - | 0.394" (10.00mm) | 0.866" Dia (22.00mm) | 1.181" (30.00mm) | - | Through Hole |
