Ceramic Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | Temperature Coefficient | Operating Temperature | Features | Ratings | Applications | Failure Rate | Mounting Type | Package / Case | Size / Dimension | Height - Seated (Max) | Thickness (Max) | Lead Spacing | Lead Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
KGM31ACG3A471JUCAP CER 470PF 1KV C0G/NP0 1206 |
1,736 |
|
Datasheet |
KGM - HV | Tape & Reel (TR) | Active | 470 pF | ±5% | 1000V (1kV) | C0G, NP0 | -55°C ~ 125°C | High Voltage | - | General Purpose | - | Surface Mount, MLCC | 1206 (3216 Metric) | 0.130" L x 0.063" W (3.30mm x 1.60mm) | - | 0.071" (1.80mm) | - | - |
|
RDE5C2A271J0S1H03ACAP CER 270PF 100V C0G/NP0 RAD |
1,705 |
|
Datasheet |
RDE | Cut Tape (CT) | Active | 270 pF | ±5% | 100V | C0G, NP0 | -55°C ~ 125°C | - | - | General Purpose | - | Through Hole | Radial | 0.197" L x 0.098" W (5.00mm x 2.50mm) | 0.236" (6.00mm) | - | 0.098" (2.50mm) | - |
|
RDE5C2A102J0K1H03BCAP CER 1000PF 100V NP0 RADIAL |
1,675 |
|
Datasheet |
RDE | Bulk | Active | 1000 pF | ±5% | 100V | C0G, NP0 | -55°C ~ 125°C | - | - | General Purpose | - | Through Hole | Radial | 0.157" L x 0.098" W (4.00mm x 2.50mm) | 0.236" (6.00mm) | - | 0.197" (5.00mm) | - |
|
RCE5C2A100J0M1H03ACAP CER 10PF 100V C0G/NP0 RADIAL |
1,665 |
|
Datasheet |
RCE | Cut Tape (CT) | Active | 10 pF | ±5% | 100V | C0G, NP0 | -55°C ~ 125°C | - | AEC-Q200 | Automotive | - | Through Hole | Radial | 0.142" L x 0.098" W (3.60mm x 2.50mm) | 0.138" (3.50mm) | - | 0.197" (5.00mm) | Formed Leads |
|
|
RDE5C1H560J0M1H03ACAP CER 56PF 50V C0G/NP0 RADIAL |
1,660 |
|
Datasheet |
RDE | Cut Tape (CT) | Active | 56 pF | ±5% | 50V | C0G, NP0 | -55°C ~ 125°C | - | - | General Purpose | - | Through Hole | Radial | 0.157" L x 0.098" W (4.00mm x 2.50mm) | 0.236" (6.00mm) | - | 0.197" (5.00mm) | - |
|
AR151C103K4RCAP CER 10000PF 100V X7R RADIAL |
1,641 |
|
Datasheet |
SkyCap® AR | Bulk | Active | 10000 pF | ±10% | 100V | X7R | -55°C ~ 125°C | - | AEC-Q200 | Automotive | - | Through Hole | Radial | 0.150" L x 0.100" W (3.81mm x 2.54mm) | 0.150" (3.81mm) | - | 0.100" (2.54mm) | Straight |
|
|
RDE5C2A3R0C0M1H03ACAP CER 3PF 100V C0G/NP0 RADIAL |
1,613 |
|
Datasheet |
RDE | Cut Tape (CT) | Active | 3 pF | ±0.25pF | 100V | C0G, NP0 | -55°C ~ 125°C | - | - | General Purpose | - | Through Hole | Radial | 0.157" L x 0.098" W (4.00mm x 2.50mm) | 0.236" (6.00mm) | - | 0.197" (5.00mm) | - |
|
|
C1210C473K5RACTUCAP CER 0.047UF 50V X7R 1210 |
1,608 |
|
Datasheet |
SMD Comm X7R | Tape & Reel (TR) | Active | 0.047 µF | ±10% | 50V | X7R | -55°C ~ 125°C | - | - | Bypass, Decoupling | - | Surface Mount, MLCC | 1210 (3225 Metric) | 0.126" L x 0.098" W (3.20mm x 2.50mm) | - | 0.035" (0.88mm) | - | - |
|
|
C0402S102J5RACTUCAP CER 1000PF 50V X7R 0402 |
1,566 |
|
Datasheet |
SMD Comm X7R FE | Tape & Reel (TR) | Active | 1000 pF | ±5% | 50V | X7R | -55°C ~ 125°C | Floating Electrode | - | General Purpose | - | Surface Mount, MLCC | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | - | 0.022" (0.55mm) | - | - |
|
RCE5C2A391J0DBH03ACAP CER 390PF 100V C0G/NP0 RAD |
1,545 |
|
Datasheet |
RCE | Cut Tape (CT) | Active | 390 pF | ±5% | 100V | C0G, NP0 | -55°C ~ 125°C | - | AEC-Q200 | Automotive | - | Through Hole | Radial | 0.142" L x 0.098" W (3.60mm x 2.50mm) | 0.138" (3.50mm) | - | 0.098" (2.50mm) | Straight |
|
C320C182J1G5TACAP CER 1800PF 5% 100V C0G RAD |
1,487 |
|
Datasheet |
GoldMax 300 Comm C0G | Bulk | Active | 1800 pF | ±5% | 100V | C0G, NP0 | -55°C ~ 125°C | Low ESL | - | General Purpose | - | Through Hole | Radial | 0.200" L x 0.125" W (5.08mm x 3.18mm) | 0.290" (7.36mm) | - | 0.100" (2.54mm) | Straight |
|
RDE5C1H150J0P1H03BCAP CER 15PF 50V NP0 RADIAL |
1,451 |
|
Datasheet |
RDE | Bulk | Active | 15 pF | ±5% | 50V | C0G, NP0 | -55°C ~ 125°C | - | - | General Purpose | - | Through Hole | Radial | 0.197" L x 0.098" W (5.00mm x 2.50mm) | 0.236" (6.00mm) | - | 0.098" (2.50mm) | Formed Leads |
|
VJ0603D4R7CXCQJHTCAP CER 4.7PF 200V C0G/NP0 0603 |
1,432 |
|
Datasheet |
VJ HIFREQ HT | Tape & Reel (TR) | Active | 4.7 pF | ±0.25pF | 200V | C0G, NP0 | -55°C ~ 200°C | High Temperature | - | RF, Microwave, High Frequency | - | Surface Mount, MLCC | 0603 (1608 Metric) | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - | 0.037" (0.94mm) | - | - |
|
|
VJ0603D6R8CXCQJHTCAP CER 6.8PF 200V C0G/NP0 0603 |
1,415 |
|
Datasheet |
VJ HIFREQ HT | Tape & Reel (TR) | Active | 6.8 pF | ±0.25pF | 200V | C0G, NP0 | -55°C ~ 200°C | High Temperature | - | RF, Microwave, High Frequency | - | Surface Mount, MLCC | 0603 (1608 Metric) | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - | 0.037" (0.94mm) | - | - |
|
|
RDE5C2A330J0P1H03BCAP CER 33PF 100V NP0 RADIAL |
1,346 |
|
Datasheet |
RDE | Bulk | Active | 33 pF | ±5% | 100V | C0G, NP0 | -55°C ~ 125°C | - | - | General Purpose | - | Through Hole | Radial | 0.197" L x 0.098" W (5.00mm x 2.50mm) | 0.236" (6.00mm) | - | 0.098" (2.50mm) | - |
|
|
RDE5C1H5R0C0M1H03ACAP CER 5PF 50V C0G/NP0 RADIAL |
1,312 |
|
Datasheet |
RDE | Cut Tape (CT) | Active | 5 pF | ±0.25pF | 50V | C0G, NP0 | -55°C ~ 125°C | - | - | General Purpose | - | Through Hole | Radial | 0.157" L x 0.098" W (4.00mm x 2.50mm) | 0.236" (6.00mm) | - | 0.197" (5.00mm) | - |
|
|
C0805C242J5GACTUCAP CER 2400PF 50V C0G/NP0 0805 |
1,305 |
|
Datasheet |
SMD Comm C0G | Tape & Reel (TR) | Active | 2400 pF | ±5% | 50V | C0G, NP0 | -55°C ~ 125°C | Low ESL | - | General Purpose | - | Surface Mount, MLCC | 0805 (2012 Metric) | 0.079" L x 0.049" W (2.00mm x 1.25mm) | - | 0.035" (0.88mm) | - | - |
|
|
RDE5C2A220J0P1H03BCAP CER 22PF 100V NP0 RADIAL |
1,301 |
|
Datasheet |
RDE | Bulk | Active | 22 pF | ±5% | 100V | C0G, NP0 | -55°C ~ 125°C | - | - | General Purpose | - | Through Hole | Radial | 0.197" L x 0.098" W (5.00mm x 2.50mm) | 0.236" (6.00mm) | - | 0.098" (2.50mm) | - |
|
C322C105M5U5TACAP CER 1UF 50V Z5U RADIAL |
1,286 |
|
Datasheet |
GoldMax 300 Comm Z5U | Bulk | Active | 1 µF | ±20% | 50V | Z5U | 10°C ~ 85°C | - | - | General Purpose | - | Through Hole | Radial | 0.200" L x 0.125" W (5.08mm x 3.18mm) | 0.260" (6.60mm) | - | 0.200" (5.08mm) | Formed Leads |
|
|
RDE5C2A680J0K1H03BCAP CER 68PF 100V NP0 RADIAL |
1,106 |
|
Datasheet |
RDE | Bulk | Active | 68 pF | ±5% | 100V | C0G, NP0 | -55°C ~ 125°C | - | - | General Purpose | - | Through Hole | Radial | 0.157" L x 0.098" W (4.00mm x 2.50mm) | 0.236" (6.00mm) | - | 0.197" (5.00mm) | - |
