Film Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Capacitance | Tolerance | Voltage Rating - AC | Voltage Rating - DC | Dielectric Material | ESR (Equivalent Series Resistance) | Operating Temperature | Mounting Type | Size / Dimension | Height - Seated (Max) | Termination | Lead Spacing | Applications | Ratings | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
BFC238374113CAP FILM 0.011UF 5% 2.5KVDC RAD |
9,251 |
|
Datasheet |
Radial | 0.011 µF | ±5% | 900V | 2500V (2.5kV) | Polypropylene (PP), Metallized | - | -55°C ~ 105°C | Through Hole | 1.024" L x 0.335" W (26.00mm x 8.50mm) | 0.709" (18.00mm) | PC Pins | 0.886" (22.50mm) | High Pulse, DV/DT | - | - |
|
|
R75PW4390AA40JCAP FILM AUTO POLYPROP RAD |
7,063 |
|
Datasheet |
Radial | 3.9 µF | ±5% | 250V | 630V | Polypropylene (PP), Metallized | - | -55°C ~ 105°C | Through Hole | 1.634" L x 0.748" W (41.50mm x 19.00mm) | 1.264" (32.10mm) | PC Pins | 1.476" (37.50mm) | High Frequency, Switching; High Pulse, DV/DT | - | - |
|
BFC241874304CAP FILM 0.43UF 2% 250VDC RADIAL |
5,562 |
|
Datasheet |
Radial | 0.43 µF | ±2% | 25V | 250V | Polypropylene (PP), Metallized | - | -55°C ~ 85°C | Through Hole | 0.689" L x 0.335" W (17.50mm x 8.50mm) | 0.591" (15.00mm) | PC Pins | 0.591" (15.00mm) | High Frequency, Switching | - | - |
|
|
MKP385E51285JKI2B0CAP FILM 1.2UF 5% 850VDC RAD |
4,619 |
|
Datasheet |
Radial | 1.2 µF | ±5% | 300V | 850V | Polypropylene (PP), Metallized | 10 mOhms | -40°C ~ 105°C | Through Hole | - | - | PC Pins | 1.083" (27.50mm) | Automotive; High Frequency, Switching; High Pulse, DV/DT; Snubber | AEC-Q200 | High Temperature |
|
|
MKP385E51285JKP2T0CAP FILM 1.2UF 5% 850VDC RAD |
4,412 |
|
Datasheet |
Radial | 1.2 µF | ±5% | 300V | 850V | Polypropylene (PP), Metallized | 10 mOhms | -40°C ~ 105°C | Through Hole | - | - | PC Pins | 1.083" (27.50mm) | Automotive; High Frequency, Switching; High Pulse, DV/DT; Snubber | AEC-Q200 | High Temperature |
|
|
MKP385E51285JKM2T0CAP FILM 1.2UF 5% 850VDC RAD |
6,204 |
|
Datasheet |
Radial | 1.2 µF | ±5% | 300V | 850V | Polypropylene (PP), Metallized | 10 mOhms | -40°C ~ 105°C | Through Hole | - | - | PC Pins | 1.083" (27.50mm) | Automotive; High Frequency, Switching; High Pulse, DV/DT; Snubber | AEC-Q200 | High Temperature |
|
|
BFC237872273CAP FILM 0.027UF 5% 1KVDC RADIAL |
7,782 |
|
Datasheet |
Radial | 0.027 µF | ±5% | 300V | 1000V (1kV) | Polypropylene (PP), Metallized | - | -55°C ~ 85°C | Through Hole | 1.024" L x 0.236" W (26.00mm x 6.00mm) | 0.610" (15.50mm) | PC Pins | 0.886" (22.50mm) | High Pulse, DV/DT | - | Long Life |
|
|
BFC237874273CAP FILM 0.027UF 5% 1KVDC RADIAL |
2,300 |
|
Datasheet |
Radial | 0.027 µF | ±5% | 300V | 1000V (1kV) | Polypropylene (PP), Metallized | - | -55°C ~ 85°C | Through Hole | 1.024" L x 0.236" W (26.00mm x 6.00mm) | 0.610" (15.50mm) | PC Pins | 0.886" (22.50mm) | High Pulse, DV/DT | - | Long Life |
|
MKT1820547255VCAP FILM 4.7UF 10% 250VDC RADIAL |
2,153 |
|
Datasheet |
Radial | 4.7 µF | ±10% | 160V | 250V | Polyester, Metallized | - | -55°C ~ 125°C | Through Hole | 1.260" L x 0.433" W (32.00mm x 11.00mm) | 0.827" (21.00mm) | PC Pins | 1.083" (27.50mm) | DC Link, DC Filtering | - | - |
|
|
MKT1820547256VCAP FILM 4.7UF 20% 250VDC RADIAL |
9,867 |
|
Datasheet |
Radial | 4.7 µF | ±20% | 160V | 250V | Polyester, Metallized | - | -55°C ~ 125°C | Through Hole | 1.260" L x 0.433" W (32.00mm x 11.00mm) | 0.827" (21.00mm) | PC Pins | 1.083" (27.50mm) | DC Link, DC Filtering | - | - |
|
|
BFC247990115CAP FILM 0.68UF 5% 160VDC RADIAL |
8,874 |
|
Datasheet |
Radial | 0.68 µF | ±5% | 100V | 160V | Polypropylene (PP), Metallized | - | -55°C ~ 105°C | Through Hole | 0.728" L x 0.354" W (18.50mm x 9.00mm) | 0.827" (21.00mm) | PC Pins | 0.591" (15.00mm) | High Pulse, DV/DT | - | Long Life |
|
|
EFDKS1BJ905E114BHCAP EFDKS 1100VDC 9UF J 4LEADS |
4,772 |
|
Datasheet |
Radial - 4 Leads | 9 µF | ±5% | - | 1100V (1.1kV) | Polypropylene (PP), Metallized | 13 mOhms | -40°C ~ 105°C | Through Hole | 1.654" L x 0.866" W (42.00mm x 22.00mm) | 1.496" (38.00mm) | PC Pins | 1.476" (37.50mm) | DC Link, DC Filtering | - | - |
|
|
EFDKS1BJ805E114BHCAP EFDKS 1100VDC 8UF J 4LEADS |
3,238 |
|
Datasheet |
Radial - 4 Leads | 8 µF | ±5% | - | 1100V (1.1kV) | Polypropylene (PP), Metallized | 16.5 mOhms | -40°C ~ 105°C | Through Hole | 1.654" L x 0.866" W (42.00mm x 22.00mm) | 1.496" (38.00mm) | PC Pins | 1.476" (37.50mm) | DC Link, DC Filtering | - | - |
|
|
R71MR4680AA00KCAP FILM METAL RAD POLYPROP |
7,872 |
|
Datasheet |
Radial | 6.8 µF | ±10% | 220V | 420V | Polypropylene (PP), Metallized | 18 mOhms | -55°C ~ 105°C | Through Hole | 1.260" L x 0.866" W (32.00mm x 22.00mm) | 1.461" (37.10mm) | PC Pins | 1.083" (27.50mm) | High Frequency, Switching; High Pulse, DV/DT; Power Factor Correction (PFC) | - | - |
|
|
BFC241608204CAP FILM 0.82UF 5% 63VDC RADIAL |
3,650 |
|
Datasheet |
Radial | - | - | - | - | Polypropylene (PP), Metallized | - | -55°C ~ 85°C | Through Hole | 0.689" L x 0.335" W (17.50mm x 8.50mm) | 0.728" (18.50mm) | PC Pins | 0.591" (15.00mm) | High Frequency, Switching | - | Long Life |
|
|
BFC241707504CAP FILM 0.75UF 5% 160VDC RADIAL |
8,633 |
|
Datasheet |
Radial | - | - | - | - | Polypropylene (PP), Metallized | - | -55°C ~ 85°C | Through Hole | 0.689" L x 0.335" W (17.50mm x 8.50mm) | 0.728" (18.50mm) | PC Pins | 0.591" (15.00mm) | High Frequency, Switching | - | Long Life |
_06x00KSSD.jpg)
|
MKP4F046806G00KSSDCAP FILM 6.8UF 10% 250VDC RAD |
6,216 |
|
Datasheet |
Radial | 6.8 µF | ±10% | 160V | 250V | Polypropylene (PP), Metallized | - | -55°C ~ 100°C | Through Hole | 1.240" L x 0.669" W (31.50mm x 17.00mm) | 1.142" (29.00mm) | PC Pins | 1.083" (27.50mm) | High Frequency, Switching | - | - |
|
MKP1848H54080JK2CAP FILM 4UF 5% 800VDC RADIAL |
3,181 |
|
Datasheet |
Radial | 4 µF | ±5% | - | 800V | Polypropylene (PP), Metallized | 9.8 mOhms | -40°C ~ 85°C | Through Hole | 1.260" L x 0.709" W (32.00mm x 18.00mm) | 1.130" (28.70mm) | PC Pins | 1.083" (27.50mm) | Automotive; DC Link, DC Filtering | AEC-Q200 | 85C/85% Humidity; Low ESR, Low ESL |
|
|
A50MT4150AA60JCAP FILM AXL |
3,257 |
|
Datasheet |
Axial | 1.5 µF | ±5% | 200V | 400V | Polyester, Polyethylene Terephthalate (PET), Metallized | - | -55°C ~ 105°C | Through Hole | 0.492" Dia x 1.299" L (12.50mm x 33.00mm) | - | PC Pins | - | Automotive | AEC-Q200 | - |
|
MKT1820568065CAP FILM 6.8UF 10% 63VDC RADIAL |
4,743 |
|
Datasheet |
Radial | 6.8 µF | ±10% | 40V | 63V | Polyester, Metallized | - | -55°C ~ 125°C | Through Hole | 0.709" L x 0.335" W (18.00mm x 8.50mm) | 0.571" (14.50mm) | PC Pins | 0.591" (15.00mm) | DC Link, DC Filtering | - | - |
