Film Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Capacitance | Tolerance | Voltage Rating - AC | Voltage Rating - DC | Dielectric Material | ESR (Equivalent Series Resistance) | Operating Temperature | Mounting Type | Size / Dimension | Height - Seated (Max) | Termination | Lead Spacing | Applications | Ratings | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
BFC238330114CAP FILM 0.11UF 5% 1KVDC RADIAL |
6,170 |
|
Datasheet |
Radial | 0.11 µF | ±5% | 350V | 1000V (1kV) | Polypropylene (PP), Metallized | - | -55°C ~ 105°C | Through Hole | 1.024" L x 0.394" W (26.00mm x 10.00mm) | 0.768" (19.50mm) | PC Pins | 0.886" (22.50mm) | High Pulse, DV/DT | - | - |
|
BFC238331114CAP FILM 0.11UF 5% 1KVDC RADIAL |
5,628 |
|
Datasheet |
Radial | 0.11 µF | ±5% | 350V | 1000V (1kV) | Polypropylene (PP), Metallized | - | -55°C ~ 105°C | Through Hole | 1.024" L x 0.394" W (26.00mm x 10.00mm) | 0.768" (19.50mm) | PC Pins | 0.886" (22.50mm) | High Pulse, DV/DT | - | - |
|
|
BFC238334114CAP FILM 0.11UF 5% 1KVDC RADIAL |
7,634 |
|
Datasheet |
Radial | 0.11 µF | ±5% | 350V | 1000V (1kV) | Polypropylene (PP), Metallized | - | -55°C ~ 105°C | Through Hole | 1.024" L x 0.394" W (26.00mm x 10.00mm) | 0.768" (19.50mm) | PC Pins | 0.886" (22.50mm) | High Pulse, DV/DT | - | - |
|
|
BFC238341513CAP FILM 0.051UF 5% 1.4KVDC RAD |
3,283 |
|
Datasheet |
Radial | 0.051 µF | ±5% | 500V | 1400V (1.4kV) | Polypropylene (PP), Metallized | - | -55°C ~ 105°C | Through Hole | 1.220" L x 0.433" W (31.00mm x 11.00mm) | 0.827" (21.00mm) | PC Pins | 1.083" (27.50mm) | High Pulse, DV/DT | - | - |
|
MKP1839447134HQCAP FILM 0.47UF 5% 1.6KVDC AXIAL |
7,515 |
|
Datasheet |
Axial | 0.47 µF | ±5% | 450V | 1600V (1.6kV) | Polypropylene (PP), Metallized | - | -55°C ~ 110°C | Through Hole | 0.925" Dia x 1.240" L (23.50mm x 31.50mm) | - | PC Pins | - | High Pulse, DV/DT | - | - |
|
|
MKT1813610014RCAP FILM 10UF 5% 100VDC AXIAL |
9,725 |
|
Datasheet |
Axial | 10 µF | ±5% | 63V | 100V | Polyester, Metallized | - | -55°C ~ 100°C | Through Hole | 0.650" Dia x 1.240" L (16.50mm x 31.50mm) | - | PC Pins | - | General Purpose | - | - |
|
DPM2W4P7K-FCAP FILM 4.7UF 10% 250VDC RADIAL |
8,082 |
|
Datasheet |
Radial | 4.7 µF | ±10% | 160V | 250V | Polypropylene (PP), Metallized | - | -55°C ~ 105°C | Through Hole | 1.850" L x 0.787" W (47.00mm x 20.00mm) | 1.299" (33.00mm) | PC Pins | 1.575" (40.00mm) | DC Link, DC Filtering; High Frequency, Switching | - | Low ESR, Low ESL |
|
|
R75IR4820AA40KCAP FILM AUTO POLYPROP RAD |
9,233 |
|
Datasheet |
Radial | 8.2 µF | ±10% | 160V | 250V | Polypropylene (PP), Metallized | 5.8 mOhms | -55°C ~ 105°C | Through Hole | 1.260" L x 0.709" W (32.00mm x 18.00mm) | 1.303" (33.10mm) | PC Pins | 1.083" (27.50mm) | High Frequency, Switching; High Pulse, DV/DT | - | - |
|
|
MKP1T041007L00KSSDMKP 10 1.0 F 1600 VDC 28X38X41.5 |
3,922 |
|
Datasheet |
- | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
R76TW3680SE30KCAP FILM AUTO POLYPROP RAD |
5,909 |
|
Datasheet |
Radial | 0.68 µF | ±10% | 650V | 1600V (1.6kV) | Polypropylene (PP), Metallized | 11 mOhms | -55°C ~ 110°C | Through Hole | 1.634" L x 0.787" W (41.50mm x 20.00mm) | 1.579" (40.10mm) | PC Pins | 1.476" (37.50mm) | High Frequency, Switching; High Pulse, DV/DT | - | - |
|
|
R76PW4220SE30KCAP FILM AUTO POLYPROP RAD |
7,782 |
|
Datasheet |
Radial | 2.2 µF | ±10% | 400V | 630V | Polypropylene (PP), Metallized | 8.7 mOhms | -55°C ~ 110°C | Through Hole | 1.634" L x 0.787" W (41.50mm x 20.00mm) | 1.579" (40.10mm) | PC Pins | 1.476" (37.50mm) | High Frequency, Switching; High Pulse, DV/DT | - | - |
|
|
F462FS394R1K6ZCAP |
3,182 |
|
- |
- | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
MKP1848580454K2CAP FILM 8UF 5% 450VDC RADIAL |
6,565 |
|
Datasheet |
Radial | 8 µF | ±5% | - | 450V | Polypropylene (PP), Metallized | 8.5 mOhms | -40°C ~ 105°C | Through Hole | 1.260" L x 0.709" W (32.00mm x 18.00mm) | 1.102" (28.00mm) | PC Pins | 1.083" (27.50mm) | Automotive; DC Link, DC Filtering | AEC-Q200 | Low ESR |
|
MKP1848550094P4CAP FILM 5UF 5% 900VDC RADIAL |
5,279 |
|
Datasheet |
Radial - 4 Leads | 5 µF | ±5% | - | 900V | Polypropylene (PP), Metallized | 19 mOhms | -40°C ~ 105°C | Through Hole | 1.693" L x 0.728" W (43.00mm x 18.50mm) | 1.398" (35.50mm) | PC Pins | 1.476" (37.50mm) | Automotive; DC Link, DC Filtering | AEC-Q200 | Low ESR |
|
|
MKP1848560094P2CAP FILM 6UF 5% 900VDC RADIAL |
4,700 |
|
Datasheet |
Radial | 6 µF | ±5% | - | 900V | Polypropylene (PP), Metallized | 18 mOhms | -40°C ~ 105°C | Through Hole | 1.693" L x 0.728" W (43.00mm x 18.50mm) | 1.398" (35.50mm) | PC Pins | 1.476" (37.50mm) | Automotive; DC Link, DC Filtering | AEC-Q200 | Low ESR |
|
|
EFDKA55J306E154BHCAP EFDKA 550VDC 30UF J 4LEADS |
5,664 |
|
Datasheet |
Radial - 4 Leads | 30 µF | ±5% | - | 550V | Polypropylene (PP), Metallized | 7.2 mOhms | -55°C ~ 105°C | Through Hole | 1.654" L x 0.945" W (42.00mm x 24.00mm) | 1.772" (45.00mm) | PC Pins | 1.476" (37.50mm) | Automotive; DC Link, DC Filtering | AEC-Q200 | - |
|
|
EFDKA90J206E154BHCAP EFDKA 900VDC 20UF J 4LEADS |
4,219 |
|
Datasheet |
Radial - 4 Leads | 20 µF | ±5% | - | 900V | Polypropylene (PP), Metallized | 7.5 mOhms | -55°C ~ 105°C | Through Hole | 1.654" L x 0.945" W (42.00mm x 24.00mm) | 1.772" (45.00mm) | PC Pins | 1.476" (37.50mm) | Automotive; DC Link, DC Filtering | AEC-Q200 | - |
|
QAK2J225KTPCAP FILM 2.2UF 10% 630VDC AXIAL |
2,103 |
|
Datasheet |
Axial | 2.2 µF | ±10% | - | 630V | Polyester, Metallized | - | -40°C ~ 85°C | Through Hole | 1.083" W, 0.650" T x 1.969" L (27.50mm, 16.50mm x 50.00mm) | - | PC Pins | - | General Purpose | - | - |
|
MKP1848H56080JK2CAP FILM 6UF 5% 800VDC RADIAL |
3,861 |
|
Datasheet |
Radial | 6 µF | ±5% | - | 800V | Polypropylene (PP), Metallized | 7.4 mOhms | -40°C ~ 85°C | Through Hole | 1.260" L x 0.827" W (32.00mm x 21.00mm) | 1.248" (31.70mm) | PC Pins | 1.083" (27.50mm) | Automotive; DC Link, DC Filtering | AEC-Q200 | 85C/85% Humidity; Low ESR, Low ESL |
|
BLH126K601B012DC LINK, THB, 85/85, AEC-Q200 |
2,994 |
|
Datasheet |
Radial | 12 µF | ±10% | - | 600V | Polypropylene (PP), Metallized | 9.5 mOhms | -40°C ~ 105°C | Through Hole | 1.673" L x 0.945" W (42.50mm x 24.00mm) | 0.740" (18.80mm) | PC Pins | 1.476" (37.50mm) | Automotive; DC Link, DC Filtering | AEC-Q200 | 85C/85% Humidity, THB, Low ESR, Low ESL, Long Life |
