Aluminum Electrolytic Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Polarization | Ratings | Applications | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PEH532SCE3680M2CAP ALUM SNAP-IN 105C |
0 |
|
Datasheet |
PEH532 | Box | Active | 680 µF | ±20% | 250 V | 170mOhm @ 100Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.6 A @ 100 Hz | 4.5 A @ 20 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
|
B41689A7278Q001CAP ALUM 2700UF 40V AXIAL TH |
0 |
|
Datasheet |
B41689 | Bulk | Active | 2700 µF | -10%, +30% | 40 V | 123mOhm @ 100Hz | 10000 Hrs @ 125°C | -55°C ~ 125°C | Polar | - | Automotive | - | 10.1 A @ 10 kHz | 12 mOhms | - | 0.827" Dia x 1.929" L (21.00mm x 49.00mm) | - | - | Through Hole | |
|
ALC70A911CF250CAP ALUM 910UF 20% 250V SNAP TH |
0 |
|
Datasheet |
ALC70 | Bulk | Active | 910 µF | ±20% | 250 V | 200mOhm @ 100Hz | 13000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 2.88 A @ 100 Hz | 6.21 A @ 10 kHz | 116 mOhms | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
|
ALC70D911CF250CAP ALUM 910UF 20% 250V SNAP TH |
0 |
|
Datasheet |
ALC70 | Bulk | Active | 910 µF | ±20% | 250 V | 200mOhm @ 100Hz | 13000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 2.88 A @ 100 Hz | 6.21 A @ 10 kHz | 116 mOhms | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
ALC70F911CF250CAP ALUM 910UF 20% 250V SNAP TH |
0 |
|
Datasheet |
ALC70 | Bulk | Active | 910 µF | ±20% | 250 V | 200mOhm @ 100Hz | 13000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 2.88 A @ 100 Hz | 6.21 A @ 10 kHz | 116 mOhms | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
MAL211816332E3CAP ALUM 3300UF 20% 25V AXIAL TH |
0 |
|
Datasheet |
118 AHT | Bulk | Active | 3300 µF | ±20% | 25 V | 120mOhm | 8000 Hrs @ 125°C | -55°C ~ 125°C | Polar | - | Automotive | - | 1.932 A @ 10 kHz | 110 mOhms | - | 0.709" Dia x 1.496" L (18.00mm x 38.00mm) | - | - | Through Hole | |
|
|
MAL211819331E3CAP ALUM 330UF 20% 100V AXIAL TH |
0 |
|
Datasheet |
118 AHT | Bulk | Active | 330 µF | ±20% | 100 V | 450mOhm | 8000 Hrs @ 125°C | -55°C ~ 125°C | Polar | - | Automotive | - | 1.246 A @ 10 kHz | 370 mOhms | - | 0.709" Dia x 1.496" L (18.00mm x 38.00mm) | - | - | Through Hole | |
|
35MXC12000MEFCSN35X30CAP ALUM 12000UF 20% 35V SNAP TH |
0 |
|
Datasheet |
MXC | Bulk | Not For New Designs | 12000 µF | ±20% | 35 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3.37 A @ 120 Hz | 3.8755 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
|
B43630A9477M060CAP ALUM 400V POLAR |
0 |
|
Datasheet |
B43630 | Bulk | Active | 470 µF | ±20% | 400 V | 240mOhm @ 100Hz | 2000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 2.5 A @ 100 Hz | - | 380 mOhms | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
ALC70C103DD063CAP ALUM 10000UF 20% 63V SNAP TH |
0 |
|
Datasheet |
ALC70 | Bulk | Active | 10000 µF | ±20% | 63 V | 44mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 6.55 A @ 100 Hz | 8.44 A @ 10 kHz | 34 mOhms | 0.886" (22.50mm) | 1.378" Dia (35.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
|
ALC70D103DD063CAP ALUM 10000UF 20% 63V SNAP TH |
0 |
|
Datasheet |
ALC70 | Bulk | Active | 10000 µF | ±20% | 63 V | 44mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 6.55 A @ 100 Hz | 8.44 A @ 10 kHz | 34 mOhms | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
|
ALC70F103DD063CAP ALUM 10000UF 20% 63V SNAP TH |
0 |
|
Datasheet |
ALC70 | Bulk | Active | 10000 µF | ±20% | 63 V | 44mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 6.55 A @ 100 Hz | 8.44 A @ 10 kHz | 34 mOhms | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
ALF40C123DC040CAP ALUM 12000UF 20% 40V PRESS |
0 |
|
Datasheet |
ALF40 | Bulk | Active | 12000 µF | ±20% | 40 V | 121mOhm @ 100Hz | 8000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.77 A @ 100 Hz | 3.08 A @ 10 kHz | 106 mOhms | 0.886" (22.50mm) | 1.378" Dia (35.00mm) | 1.457" (37.00mm) | - | Through Hole, Press-Fit | |
|
ALC80D203DF040CAP ALUM 20000UF 20% 40V SNAP TH |
0 |
|
Datasheet |
ALC80 | Bulk | Active | 20000 µF | ±20% | 40 V | 30mOhm @ 100Hz | 8000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 9.1 A @ 100 Hz | 11.36 A @ 10 kHz | 25 mOhms | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
|
100VXG2700MEFC30X45CAP ALUM 2700UF 20% 100V SNAP TH |
0 |
|
Datasheet |
VXG | Bulk | Active | 2700 µF | ±20% | 100 V | - | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.86 A @ 120 Hz | 3.289 A @ 10 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.850" (47.00mm) | - | Through Hole | |
|
400VXG390MEFC35X35CAP ALUM 390UF 20% 400V SNAP TH |
0 |
|
Datasheet |
VXG | Bulk | Active | 390 µF | ±20% | 400 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.74 A @ 120 Hz | 2.436 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
|
450MXH390MEFC35X35CAP ALUM 390UF 20% 450V SNAP TH |
0 |
|
Datasheet |
MXH | Bulk | Active | 390 µF | ±20% | 450 V | - | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.76 A @ 120 Hz | 2.464 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
|
63VXG3900MEFC35X30CAP ALUM 3900UF 20% 63V SNAP TH |
0 |
|
Datasheet |
VXG | Bulk | Active | 3900 µF | ±20% | 63 V | - | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.31 A @ 120 Hz | 2.6565 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
|
450MXC120MEFC20X50CAP ALUM 120UF 20% 450V SNAP TH |
0 |
|
Datasheet |
MXC | Bulk | Not For New Designs | 120 µF | ±20% | 450 V | - | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 750 mA @ 120 Hz | 1.05 A @ 10 kHz | - | 0.394" (10.00mm) | 0.787" Dia (20.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
MAL211945152E3CAP ALUM 1500UF 16V AXIAL TH |
0 |
|
Datasheet |
119 AHT-DIN | Tape & Reel (TR) | Active | 1500 µF | -10%, +50% | 16 V | 210mOhm @ 100Hz | 8000 Hrs @ 125°C | -55°C ~ 125°C | Polar | - | General Purpose | 1.12 A @ 100 Hz | - | 170 mOhms | - | 0.709" Dia (18.00mm) | 1.299" (33.00mm) | - | Through Hole |
