Aluminum Electrolytic Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Polarization | Ratings | Applications | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ELHS4H1VSN391MA40SCAP ALUM 390UF 20% 475V SNAP TH |
0 |
|
Datasheet |
LHS | Bulk | Active | 390 µF | ±20% | 475 V | - | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.7 A @ 120 Hz | 2.431 A @ 50 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.673" (42.50mm) | - | Through Hole | |
|
LSR561M2G---3545SCAP ALUM 400V POLAR |
0 |
|
- |
LSR | Active | 560 µF | ±20% | 400 V | 213mOhm @ 120Hz | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 3.18 A @ 120 Hz | 4.452 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.850" (47.00mm) | - | Through Hole | ||
|
|
475VXT330MEFCSN25X45CAP ALUM 330UF 20% 475V SNAP TH |
0 |
|
Datasheet |
VXT | Bulk | Active | 330 µF | ±20% | 475 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.72 A @ 120 Hz | 2.408 A @ 10 kHz | - | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.850" (47.00mm) | - | Through Hole | |
|
ELXS251VSN122MA35SCAP ALUM 1200UF 20% 250V SNAP TH |
0 |
|
Datasheet |
LXS | Bulk | Active | 1200 µF | ±20% | 250 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 3 A @ 120 Hz | 4.5 A @ 50 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.476" (37.50mm) | - | Through Hole | |
|
ALC80C391DD400CAP ALUM 390UF 20% 400V SNAP TH |
0 |
|
Datasheet |
ALC80 | Bulk | Active | 390 µF | ±20% | 400 V | 316mOhm @ 100Hz | 8000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.28 A @ 100 Hz | 6.15 A @ 10 kHz | 163 mOhms | 0.886" (22.50mm) | 1.378" Dia (35.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
ALC80D391DD400CAP ALUM 390UF 20% 400V SNAP TH |
0 |
|
Datasheet |
ALC80 | Bulk | Active | 390 µF | ±20% | 400 V | 316mOhm @ 100Hz | 8000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.28 A @ 100 Hz | 6.15 A @ 10 kHz | 163 mOhms | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
|
ALC80E391DD400CAP ALUM 390UF 20% 400V SNAP TH |
0 |
|
Datasheet |
ALC80 | Bulk | Active | 390 µF | ±20% | 400 V | 316mOhm @ 100Hz | 8000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.28 A @ 100 Hz | 6.15 A @ 10 kHz | 163 mOhms | 0.886" (22.50mm) | 1.378" Dia (35.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
ALC80F391DD400CAP ALUM 390UF 20% 400V SNAP TH |
0 |
|
Datasheet |
ALC80 | Bulk | Active | 390 µF | ±20% | 400 V | 316mOhm @ 100Hz | 8000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.28 A @ 100 Hz | 6.15 A @ 10 kHz | 163 mOhms | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
200HXG1000MEFCSN25X45CAP ALUM 1000UF 20% 200V SNAP TH |
0 |
|
Datasheet |
HXG | Bulk | Active | 1000 µF | ±20% | 200 V | - | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | - | - | - | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.850" (47.00mm) | - | Through Hole | |
|
|
ALC40A223DC025CAP ALUM SNAP-IN 105C |
0 |
|
Datasheet |
ALC40 | Box | Active | 22 mF | ±20% | 25 V | 116mOhm @ 100Hz | 8000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.91 A @ 100 Hz | 3.1 A @ 10 kHz | 104 mOhms | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
672D108F012DS5JCAP ALUM 1000UF 12V RADIAL TH |
0 |
|
Datasheet |
672D | Bulk | Active | 1000 µF | -10%, +50% | 12 V | 150mOhm @ 120Hz | - | -55°C ~ 105°C | Polar | - | General Purpose | 1.645 A @ 120 Hz | 235 mA @ 100 kHz | 60 mOhms | 0.197" (5.00mm) | 0.492" Dia (12.50mm) | 1.791" (45.50mm) | - | Through Hole | |
|
ALC70A751DF350CAP ALUM 750UF 20% 350V SNAP TH |
0 |
|
Datasheet |
ALC70 | Bulk | Active | 750 µF | ±20% | 350 V | 190mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 3.09 A @ 100 Hz | 7.15 A @ 10 kHz | 100 mOhms | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
ALC70C751DF350CAP ALUM 750UF 20% 350V SNAP TH |
0 |
|
Datasheet |
ALC70 | Bulk | Active | 750 µF | ±20% | 350 V | 190mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 3.09 A @ 100 Hz | 7.15 A @ 10 kHz | 100 mOhms | 0.886" (22.50mm) | 1.378" Dia (35.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
|
ALC70D751DF350CAP ALUM 750UF 20% 350V SNAP TH |
0 |
|
Datasheet |
ALC70 | Bulk | Active | 750 µF | ±20% | 350 V | 190mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 3.09 A @ 100 Hz | 7.15 A @ 10 kHz | 100 mOhms | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
|
ALC70E751DF350CAP ALUM 750UF 20% 350V SNAP TH |
0 |
|
Datasheet |
ALC70 | Bulk | Active | 750 µF | ±20% | 350 V | 190mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 3.09 A @ 100 Hz | 7.15 A @ 10 kHz | 100 mOhms | 0.886" (22.50mm) | 1.378" Dia (35.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
ALC70F751DF350CAP ALUM 750UF 20% 350V SNAP TH |
0 |
|
Datasheet |
ALC70 | Bulk | Active | 750 µF | ±20% | 350 V | 190mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 3.09 A @ 100 Hz | 7.15 A @ 10 kHz | 100 mOhms | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
LGNW6391MELC35CAP ALUM 390UF 20% 420V SNAP TH |
0 |
|
Datasheet |
LGN | Bulk | Active | 390 µF | ±20% | 420 V | - | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.61 A @ 120 Hz | 2.3023 A @ 50 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
|
400VXH470MEFC30X40CAP ALUM 470UF 20% 400V SNAP TH |
0 |
|
Datasheet |
VXH | Bulk | Active | 470 µF | ±20% | 400 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.93 A @ 120 Hz | 2.702 A @ 10 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
|
ALC70A221CD500CAP ALUM 220UF 20% 500V SNAP TH |
0 |
|
Datasheet |
ALC70 | Bulk | Active | 220 µF | ±20% | 500 V | 912.6mOhm @ 100Hz | 13000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 1.55 A @ 100 Hz | 3.36 A @ 10 kHz | 646 mOhms | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
ELXS421VSN471MR50SCAP ALUM 470UF 20% 420V SNAP TH |
0 |
|
Datasheet |
LXS | Bulk | Active | 470 µF | ±20% | 420 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.9 A @ 120 Hz | 2.717 A @ 50 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 2.067" (52.50mm) | - | Through Hole |
