Aluminum Electrolytic Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Polarization | Ratings | Applications | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MAL250119562E3CAP ALUM 5600UF 20% 500V SCREW |
0 |
|
Datasheet |
501 PGM-ST | Box | Active | 5600 µF | ±20% | 500 V | 45mOhm @ 100Hz | 5000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 16.3 A @ 100 Hz | 24.45 A @ 10 kHz | 37 mOhms | 1.252" (31.80mm) | 3.008" Dia (76.40mm) | 5.780" (146.80mm) | - | Chassis Mount | |
|
LNT2W123MSEJBBCAP ALUM 12000UF 20% 450V SCREW |
0 |
|
Datasheet |
LNT | Bulk | Active | 12000 µF | ±20% | 450 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 39.2 A @ 120 Hz | 54.88 A @ 10 kHz | - | 1.252" (31.80mm) | 3.543" Dia (90.00mm) | 9.173" (233.00mm) | - | Chassis Mount | |
|
|
LNT2W123MSEJBNCAP ALUM 12000UF 20% 450V SCREW |
0 |
|
Datasheet |
LNT | Bulk | Active | 12000 µF | ±20% | 450 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 39.2 A @ 120 Hz | 54.88 A @ 10 kHz | - | 1.252" (31.80mm) | 3.543" Dia (90.00mm) | 9.173" (233.00mm) | - | Chassis Mount | |
|
|
LNT1E105MSEBCAP ALUM 1F 20% 25V SCREW CHAS M |
0 |
|
Datasheet |
LNT | Bulk | Active | 1 F | ±20% | 25 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 26.4 A @ 120 Hz | 39.6 A @ 10 kHz | - | 1.634" (41.50mm) | 3.937" Dia (100.00mm) | 8.819" (224.00mm) | - | Chassis Mount | |
|
|
LNT1E105MSENCAP ALUM 1F 20% 25V SCREW CHAS M |
0 |
|
Datasheet |
LNT | Bulk | Active | 1 F | ±20% | 25 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 26.4 A @ 120 Hz | 39.6 A @ 10 kHz | - | 1.634" (41.50mm) | 3.937" Dia (100.00mm) | 8.819" (224.00mm) | - | Chassis Mount | |
|
HES172G450W4CCAP ALUM 1700UF 450V SCREW CHAS |
0 |
|
Datasheet |
HES | Bulk | Active | 1700 µF | 0%, +50% | 450 V | 51mOhm @ 120Hz | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 7.1 A @ 120 Hz | 8.733 A @ 10 kHz | - | - | 2.500" Dia (63.50mm) | 4.125" (104.78mm) | - | Chassis Mount | |
|
B43584B5478M000CAP ALUM 4700UF 20% 450V SCREW |
0 |
|
Datasheet |
B43584 | Bulk | Obsolete | 4700 µF | ±20% | 450 V | 21mOhm @ 100Hz | 15000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 15.7 A @ 100 Hz | - | 25 mOhms | 1.248" (31.70mm) | 3.028" Dia (76.90mm) | 5.677" (144.20mm) | - | Chassis, Stud Mount | |
|
|
B43720E8568M608CAP ALUM 600V POLAR |
0 |
|
Datasheet |
B43720 | Bulk | Active | 5.6 mF | ±20% | 600 V | 17mOhm @ 100Hz | 8000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 24 A @ 100 Hz | - | 28 mOhms | 1.248" (31.70mm) | 3.028" Dia (76.90mm) | 8.728" (221.70mm) | - | Chassis Mount | |
|
LNT2G123MSEJCAP ALUM 12000UF 20% 400V SCREW |
0 |
|
Datasheet |
LNT | Bulk | Active | 12000 µF | ±20% | 400 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 38.3 A @ 120 Hz | 53.62 A @ 10 kHz | - | 1.252" (31.80mm) | 3.543" Dia (90.00mm) | 8.780" (223.00mm) | - | Chassis Mount | |
|
CGS123T200W5LCAP ALUM 12000UF 200V SCREW CHAS |
0 |
|
Datasheet |
CGS | Bulk | Active | 12000 µF | -10%, +50% | 200 V | 13mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 16 A @ 120 Hz | 24 A @ 10 kHz | - | - | 2.500" Dia (63.50mm) | 5.625" (142.88mm) | - | Chassis Mount | |
|
MAL210116474E3CAP ALUM 470000UF 20% 25V SCREW |
0 |
|
Datasheet |
101 PHR-ST | Bulk | Active | 470000 µF | ±20% | 25 V | 5mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 29.9 A @ 100 Hz | - | 5 mOhms | 1.252" (31.80mm) | 2.992" Dia (76.00mm) | 8.886" (225.70mm) | - | Chassis Mount | |
|
|
MAL210156474E3CAP ALUM 470000UF 20% 25V SCREW |
0 |
|
Datasheet |
101 PHR-ST | Bulk | Active | 470000 µF | ±20% | 25 V | 5mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 29.9 A @ 100 Hz | - | 5 mOhms | 1.252" (31.80mm) | 2.992" Dia (76.00mm) | 8.886" (225.70mm) | - | Chassis Mount | |
|
|
LNX2L682MSEJBBCAP ALUM 6800UF 20% 550V SCREW |
0 |
|
Datasheet |
LNX | Bulk | Active | 6800 µF | ±20% | 550 V | - | 5000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 19.5 A @ 120 Hz | 27.3 A @ 10 kHz | - | 1.252" (31.80mm) | 3.543" Dia (90.00mm) | 8.780" (223.00mm) | - | Chassis Mount | |
|
|
LNX2L682MSEJBNCAP ALUM 6800UF 20% 550V SCREW |
0 |
|
Datasheet |
LNX | Bulk | Active | 6800 µF | ±20% | 550 V | - | 5000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 19.5 A @ 120 Hz | 27.3 A @ 10 kHz | - | 1.252" (31.80mm) | 3.543" Dia (90.00mm) | 8.780" (223.00mm) | - | Chassis Mount | |
|
|
B43724A6688M000CAP ALUM 6800UF 20% 500V SCREW |
0 |
|
Datasheet |
B43724 | Bulk | Active | 6800 µF | ±20% | 500 V | 14mOhm @ 100Hz | 12000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 22.8 A @ 100 Hz | - | 22 mOhms | 1.248" (31.70mm) | 3.027" Dia (76.90mm) | 7.547" (191.70mm) | - | Chassis Mount | |
|
|
LNC2W153MSEJBBCAP ALUM 15000UF 20% 450V SCREW |
0 |
|
Datasheet |
LNC | Bulk | Active | 15000 µF | ±20% | 450 V | - | 5000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 43.1 A @ 120 Hz | 60.34 A @ 10 kHz | - | 1.252" (31.80mm) | 3.543" Dia (90.00mm) | 8.583" (218.00mm) | - | Chassis Mount | |
|
|
LNC2W153MSEJBNCAP ALUM 15000UF 20% 450V SCREW |
0 |
|
Datasheet |
LNC | Bulk | Active | 15000 µF | ±20% | 450 V | - | 5000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 43.1 A @ 120 Hz | 60.34 A @ 10 kHz | - | 1.252" (31.80mm) | 3.543" Dia (90.00mm) | 8.583" (218.00mm) | - | Chassis Mount | |
|
|
LNC2W153MTEJCAP ALUM 15000UF 20% 450V SCREW |
0 |
|
Datasheet |
LNC | Bulk | Active | 15000 µF | ±20% | 450 V | - | 5000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 43.1 A @ 120 Hz | 60.34 A @ 10 kHz | - | 1.252" (31.80mm) | 3.543" Dia (90.00mm) | 8.583" (218.00mm) | - | Chassis Mount | |
|
|
LNX2G153MSEKBNCAP ALUM 15000UF 20% 400V SCREW |
0 |
|
Datasheet |
LNX | Bulk | Active | 15000 µF | ±20% | 400 V | - | 20000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 29.6 A @ 120 Hz | 41.44 A @ 10 kHz | - | 1.634" (41.50mm) | 3.937" Dia (100.00mm) | 7.638" (194.00mm) | - | Chassis Mount | |
|
|
B43743A9828M007CAP ALUM 8200UF 20% 400V SCREW |
0 |
|
- |
B43743 | Bulk | Active | 8200 µF | ±20% | 400 V | 11mOhm @ 100Hz | 6000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 29.4 A @ 100 Hz | - | 18 mOhms | 1.248" (31.70mm) | 3.028" Dia (76.90mm) | 5.185" (131.70mm) | - | Chassis Mount |
