Film Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Capacitance | Tolerance | Voltage Rating - AC | Voltage Rating - DC | Dielectric Material | ESR (Equivalent Series Resistance) | Operating Temperature | Mounting Type | Size / Dimension | Height - Seated (Max) | Termination | Lead Spacing | Applications | Ratings | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
B32656S7684K562CAP FILM 0.68UF 1.25KVDC SCREW |
5,391 |
|
Datasheet |
Rectangular Box | 0.68 µF | ±10% | 500V | 1250V (1.25kV) | Polypropylene (PP), Metallized | 6 mOhms | -55°C ~ 100°C | Chassis Mount | - | - | Screw Terminals | 0.866" (22.00mm) | Snubber | - | Low ESL |
|
|
B32656S7684J566CAP FILM 0.68UF 5% 1.25KVDC SCRW |
5,690 |
|
Datasheet |
Rectangular Box | 0.68 µF | ±5% | 500V | 1250V (1.25kV) | Polypropylene (PP), Metallized | 6 mOhms | -55°C ~ 100°C | Chassis Mount | 1.654" L x 0.787" W (42.00mm x 20.00mm) | 1.555" (39.50mm) | Screw Terminals | 0.945" (24.00mm) | Snubber | AEC-Q200 | Low ESL |
|
|
B32656S7684K566CAP FILM 0.68UF 1.25KVDC QC TERM |
2,278 |
|
Datasheet |
Rectangular Box | 0.68 µF | ±10% | 500V | 1250V (1.25kV) | Polypropylene (PP), Metallized | 6 mOhms | -55°C ~ 100°C | Chassis Mount | 1.654" L x 0.787" W (42.00mm x 20.00mm) | 1.555" (39.50mm) | Screw Terminals | 0.945" (24.00mm) | Snubber | AEC-Q200 | Low ESL |
|
|
DCP4P043006FB8JS00DC-LINK MKP 4 3.0 F 1100 VDC 15X |
8,319 |
|
Datasheet |
- | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
B32678G1156K000CAP FILM 15UF 10% 750VDC RADIAL |
8,761 |
|
Datasheet |
Radial | 15 µF | ±10% | - | 750V | Polypropylene (PP), Metallized | 4.5 mOhms | -40°C ~ 105°C | Through Hole | 2.264" L x 1.181" W (57.50mm x 30.00mm) | 1.772" (45.00mm) | PC Pins | 2.067" (52.50mm) | DC Link, DC Filtering | AEC-Q200 | Long Life |
|
|
SNFPR031507D3MKS00SNUBBER FKP 0.15 F 1250 VDC 15X2 |
8,848 |
|
Datasheet |
- | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
SNFPR031507D3LKS00SNUBBER FKP 0.15 F 1250 VDC 15X2 |
7,957 |
|
Datasheet |
- | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
SNFPR031507D3QKS00SNUBBER FKP 0.15 F 1250 VDC 15X2 |
3,243 |
|
Datasheet |
- | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
SNFPR031507D3KKS00SNUBBER FKP 0.15 F 1250 VDC 15X2 |
6,346 |
|
Datasheet |
- | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
SNFPR031507D3AKS00SNUBBER FKP 0.15 F 1250 VDC 15X2 |
3,999 |
|
Datasheet |
- | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
SNFPR031507D3GKS00SNUBBER FKP 0.15 F 1250 VDC 15X2 |
6,960 |
|
Datasheet |
- | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
SNFPR031507D3PKS00SNUBBER FKP 0.15 F 1250 VDC 15X2 |
4,804 |
|
Datasheet |
- | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
SNFPR031507D1AKS00SNUBBER FKP 0.15 F 1250 VDC 15X2 |
9,138 |
|
Datasheet |
- | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
SNFPR031507D1HKS00SNUBBER FKP 0.15 F 1250 VDC 15X2 |
5,278 |
|
Datasheet |
- | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
SNFPR031507D1SKS00SNUBBER FKP 0.15 F 1250 VDC 15X2 |
4,979 |
|
Datasheet |
- | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
SNFPR031507D1JKS00SNUBBER FKP 0.15 F 1250 VDC 15X2 |
7,062 |
|
Datasheet |
- | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
SNFPR031507D1IKS00SNUBBER FKP 0.15 F 1250 VDC 15X2 |
2,374 |
|
Datasheet |
- | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
MKP385556040JPI2T0CAP FILM 5.6UF 5% 400VDC RADIAL |
4,684 |
|
Datasheet |
Radial | 5.6 µF | ±5% | 200V | 400V | Polypropylene (PP), Metallized | - | -55°C ~ 110°C | Through Hole | 1.634" L x 0.709" W (41.50mm x 18.00mm) | 1.280" (32.50mm) | PC Pins | 1.476" (37.50mm) | DC Link, DC Filtering; High Frequency, Switching; High Pulse, DV/DT | - | - |
|
953BIW16KSF-FCAP FILM 16UF 10% 160VAC RADIAL |
6,296 |
|
Datasheet |
Radial - 4 Leads | 16 µF | ±10% | 160V | - | Polypropylene (PP), Metallized | 7 mOhms | -40°C ~ 85°C | Through Hole | 1.634" L x 1.102" W (41.50mm x 28.00mm) | 1.496" (38.00mm) | PC Pins | 1.476" (37.50mm) | EMI, RFI Suppression | - | - |
|
MKP1848H62070JP4CAP FILM 20UF 5% 700VDC RADIAL |
7,431 |
|
Datasheet |
Radial - 4 Leads | 20 µF | ±5% | - | 700V | Polypropylene (PP), Metallized | 3.6 mOhms | -40°C ~ 85°C | Through Hole | 1.654" L x 0.846" W (42.00mm x 21.50mm) | 1.543" (39.20mm) | PC Pins | 1.476" (37.50mm) | Automotive; DC Link, DC Filtering | AEC-Q200 | 85C/85% Humidity; Low ESR, Low ESL |
