Aluminum Electrolytic Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Polarization | Ratings | Applications | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MAL215757829E3CAP ALUM 82UF 20% 450V SNAP TH |
0 |
|
Datasheet |
157 PUM-SI | Bulk | Active | 82 µF | ±20% | 450 V | 2.4Ohm @ 100Hz | 5000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 850 mA @ 120 Hz | - | 1.29 Ohms | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.063" (27.00mm) | - | Through Hole | |
|
MAL215777829E3CAP ALUM 82UF 20% 450V SNAP TH |
0 |
|
Datasheet |
157 PUM-SI | Bulk | Active | 82 µF | ±20% | 450 V | 2.4Ohm @ 100Hz | 5000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 850 mA @ 120 Hz | - | 1.29 Ohms | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.063" (27.00mm) | - | Through Hole | |
|
PEH506JDD5150M2SCAP ALUM SNAP-IN 85C |
0 |
|
Datasheet |
PEH506 | Box | Active | 15 mF | ±20% | 35 V | 55mOhm @ 100Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 4.1 A @ 100 Hz | 7.8 A @ 100 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
MAL212045332E3CAP ALUM 3300UF 20% 16V TH |
0 |
|
Datasheet |
120 ATC | Bulk | Active | 3300 µF | ±20% | 16 V | 41mOhm | 8000 Hrs @ 125°C | -40°C ~ 125°C | - | AEC-Q200 | Automotive | - | 3.43 A @ 10 kHz | 43 mOhms | 0.364" (9.25mm) | 0.709" Dia x 1.181" L (18.00mm x 30.00mm) | - | - | Through Hole | |
|
|
MAL212047102E3CAP ALUM 1000UF 20% 40V TH |
0 |
|
Datasheet |
120 ATC | Bulk | Active | 1000 µF | ±20% | 40 V | 59mOhm | 8000 Hrs @ 125°C | -40°C ~ 125°C | - | AEC-Q200 | Automotive | - | 3.15 A @ 10 kHz | 49 mOhms | 0.364" (9.25mm) | 0.709" Dia x 1.181" L (18.00mm x 30.00mm) | - | - | Through Hole | |
|
381LX183M025A032CAP ALUM 18000UF 20% 25V SNAP TH |
0 |
|
Datasheet |
381LX | Bulk | Obsolete | 18000 µF | ±20% | 25 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3.9 A @ 120 Hz | 4.5 A @ 20 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
ALC70A820BD600CAP ALUM 82UF 20% 600V SNAP TH |
0 |
|
Datasheet |
ALC70 | Bulk | Active | 82 µF | ±20% | 600 V | 1.555Ohm @ 100Hz | 10000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 990 mA @ 100 Hz | 2.17 A @ 10 kHz | 1.074 Ohms | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
|
ALC70D820BD600CAP ALUM 82UF 20% 600V SNAP TH |
0 |
|
Datasheet |
ALC70 | Bulk | Active | 82 µF | ±20% | 600 V | 1.555Ohm @ 100Hz | 10000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 990 mA @ 100 Hz | 2.17 A @ 10 kHz | 1.074 Ohms | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
ALC70F820BD600CAP ALUM 82UF 20% 600V SNAP TH |
0 |
|
Datasheet |
ALC70 | Bulk | Active | 82 µF | ±20% | 600 V | 1.555Ohm @ 100Hz | 10000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 990 mA @ 100 Hz | 2.17 A @ 10 kHz | 1.074 Ohms | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
ALC80D271CD400CAP ALUM 270UF 20% 400V SNAP TH |
0 |
|
Datasheet |
ALC80 | Bulk | Active | 270 µF | ±20% | 400 V | 448mOhm @ 100Hz | 7000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.74 A @ 100 Hz | 5.14 A @ 10 kHz | 229 mOhms | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
ALC80F271CD400CAP ALUM 270UF 20% 400V SNAP TH |
0 |
|
Datasheet |
ALC80 | Bulk | Active | 270 µF | ±20% | 400 V | 448mOhm @ 100Hz | 7000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.74 A @ 100 Hz | 5.14 A @ 10 kHz | 229 mOhms | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
|
400MXH470MEFC25X50CAP ALUM 470UF 20% 400V SNAP TH |
0 |
|
Datasheet |
MXH | Bulk | Active | 470 µF | ±20% | 400 V | - | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 2.07 A @ 120 Hz | 2.898 A @ 10 kHz | - | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
|
420MXK330MEFC25X40CAP ALUM 330UF 20% 420V SNAP TH |
0 |
|
Datasheet |
MXK | Bulk | Active | 330 µF | ±20% | 420 V | - | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.76 A @ 120 Hz | 2.464 A @ 10 kHz | - | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
|
LSG561M2G---3540SCAP ALUM 400V POLAR |
0 |
|
- |
LSG | Active | 560 µF | ±20% | 400 V | 355mOhm @ 120Hz | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.86 A @ 120 Hz | 2.6598 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.654" (42.00mm) | - | Through Hole | ||
|
SLP221M450H3P3CAP ALUM 220UF 20% 450V SNAP TH |
0 |
|
Datasheet |
SLP0712TE (750W) | Bulk | Active | 220 µF | ±20% | 450 V | 1.508Ohm | 3000 Hrs @ 105°C | -25°C ~ 105°C | - | - | General Purpose | - | - | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.181" (30.00mm) | - | Through Hole | |
|
SLPX391M420E7P3CAP ALUM 390UF 20% 420V SNAP TH |
0 |
|
Datasheet |
SLPX | Bulk | Active | 390 µF | ±20% | 420 V | 510mOhm @ 120Hz | 3000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 2.22 A @ 120 Hz | 3.26 A @ 20 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
|
ALO8AF391CC400CAP ALUM 105C 390UF 400VDC |
0 |
|
Datasheet |
ALO8A | Tray | Active | 390 µF | ±20% | 400 V | 395mOhm @ 100Hz | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 1.79 A @ 100 Hz | 4.56 A @ 10 kHz | 197.4 mOhms | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.378" (35.00mm) | - | Through Hole, Press-Fit | |
|
|
227LMB400M2CFCAP ALUM 220UF 20% 400V SNAP TH |
0 |
|
Datasheet |
LMB | Bulk | Active | 220 µF | ±20% | 400 V | 2.30259Ohm @ 120Hz | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.15 A @ 120 Hz | 1.6905 A @ 10 kHz | - | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
|
568LMB063M2DFCAP ALUM 5600UF 20% 63V SNAP TH |
0 |
|
Datasheet |
LMB | Bulk | Active | 5600 µF | ±20% | 63 V | 88.8141mOhm @ 120Hz | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3.22 A @ 120 Hz | 4.025 A @ 10 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
381LX152M200K052CAP ALUM 1500UF 20% 200V SNAP TH |
0 |
|
Datasheet |
381LX | Bulk | Active | 1500 µF | ±20% | 200 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.5 A @ 120 Hz | 3.5 A @ 20 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 2.047" (52.00mm) | - | Through Hole |
