Ceramic Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | Temperature Coefficient | Operating Temperature | Features | Ratings | Applications | Failure Rate | Mounting Type | Package / Case | Size / Dimension | Height - Seated (Max) | Thickness (Max) | Lead Spacing | Lead Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
C1206C272F5GACTUCAP CER 2700PF 50V C0G/NP0 1206 |
3,660 |
|
Datasheet |
SMD Comm C0G | Tape & Reel (TR) | Active | 2700 pF | ±1% | 50V | C0G, NP0 | -55°C ~ 125°C | Low ESL | - | General Purpose | - | Surface Mount, MLCC | 1206 (3216 Metric) | 0.126" L x 0.063" W (3.20mm x 1.60mm) | - | 0.035" (0.88mm) | - | - |
-2,80mm.jpg)
|
18122A102JAT2ACAP CER 1000PF 200V C0G/NP0 1812 |
2,716 |
|
Datasheet |
KGM - C0G | Tape & Reel (TR) | Active | 1000 pF | ±5% | 200V | C0G, NP0 | -55°C ~ 125°C | - | - | General Purpose | - | Surface Mount, MLCC | 1812 (4532 Metric) | 0.177" L x 0.126" W (4.50mm x 3.20mm) | - | 0.057" (1.45mm) | - | - |
|
|
18122A472JAT2ACAP CER 4700PF 200V C0G/NP0 1812 |
1,775 |
|
Datasheet |
KGM - C0G | Tape & Reel (TR) | Active | 4700 pF | ±5% | 200V | C0G, NP0 | -55°C ~ 125°C | - | - | General Purpose | - | Surface Mount, MLCC | 1812 (4532 Metric) | 0.177" L x 0.126" W (4.50mm x 3.20mm) | - | 0.057" (1.45mm) | - | - |
|
C322C750JCG5TACAP CER 75PF 500V C0G/NP0 RADIAL |
442 |
|
Datasheet |
GoldMax 300 Comm C0G HV | Bulk | Active | 75 pF | ±5% | 500V | C0G, NP0 | -55°C ~ 125°C | Low ESL, High Voltage | - | General Purpose | - | Through Hole | Radial | 0.200" L x 0.150" W (5.08mm x 3.81mm) | 0.260" (6.60mm) | - | 0.200" (5.08mm) | Straight |
|
C321C101JCG5TACAP CER 100PF 500V NP0 RADIAL |
265 |
|
Datasheet |
GoldMax 300 Comm C0G HV | Bulk | Active | 100 pF | ±5% | 500V | C0G, NP0 | -55°C ~ 125°C | Low ESL, High Voltage | - | General Purpose | - | Through Hole | Radial | 0.200" L x 0.200" W (5.08mm x 5.08mm) | 0.260" (6.60mm) | - | 0.250" (6.35mm) | Formed Leads |
|
|
C2220C103MGRACTUCAP CER 10000PF 2KV X7R 2220 |
170 |
|
Datasheet |
SMD Comm X7R HV | Tape & Reel (TR) | Active | 10000 pF | ±20% | 2000V (2kV) | X7R | -55°C ~ 125°C | Low ESL, High Voltage | - | Bypass, Decoupling | - | Surface Mount, MLCC | 2220 (5750 Metric) | 0.224" L x 0.197" W (5.70mm x 5.00mm) | - | 0.087" (2.20mm) | - | - |
|
|
C315C620JCG5TACAP CER 62PF 500V C0G/NP0 RADIAL |
111 |
|
Datasheet |
GoldMax 300 Comm C0G HV | Bulk | Active | 62 pF | ±5% | 500V | C0G, NP0 | -55°C ~ 125°C | Low ESL, High Voltage | - | General Purpose | - | Through Hole | Radial | 0.150" L x 0.124" W (3.81mm x 3.14mm) | 0.190" (4.82mm) | - | 0.100" (2.54mm) | Straight |
|
SR201A102GARTR1CAP CER 1000PF 100V NP0 RADIAL |
2,956 |
|
Datasheet |
SkyCap® SR | Tape & Reel (TR) | Active | 1000 pF | ±2% | 100V | C0G, NP0 | -55°C ~ 125°C | - | - | General Purpose | - | Through Hole | Radial | 0.200" L x 0.125" W (5.08mm x 3.18mm) | 0.200" (5.08mm) | - | 0.100" (2.54mm) | Straight |
|
|
SR201A102GARCAP CER RADIAL |
2,000 |
|
Datasheet |
SkyCap® SR | Bulk | Active | 1000 pF | ±2% | 100V | C0G, NP0 | -55°C ~ 125°C | - | - | General Purpose | - | Through Hole | Radial | 0.200" L x 0.125" W (5.08mm x 3.18mm) | 0.260" (6.60mm) | - | 0.100" (2.54mm) | Straight |
|
|
1812AA102KAT1ACAP CER 1000PF 1KV C0G/NP0 1812 |
1,720 |
|
Datasheet |
- | Tape & Reel (TR) | Active | 1000 pF | ±10% | 1000V (1kV) | C0G, NP0 | -55°C ~ 125°C | High Voltage | - | General Purpose | - | Surface Mount, MLCC | 1812 (4532 Metric) | 0.181" L x 0.126" W (4.60mm x 3.20mm) | - | 0.087" (2.20mm) | - | - |
|
CGA6M1C0G3A562J200ACCAP CER 5600PF 1KV C0G/NP0 1210 |
1,580 |
|
Datasheet |
CGA | Tape & Reel (TR) | Active | 5600 pF | ±5% | 1000V (1kV) | C0G, NP0 | -55°C ~ 125°C | High Voltage | AEC-Q200 | Automotive, SMPS Filtering | - | Surface Mount, MLCC | 1210 (3225 Metric) | 0.126" L x 0.098" W (3.20mm x 2.50mm) | - | 0.087" (2.20mm) | - | - |
|
|
CGA6M1C0G3A392J200ACCAP CER 3900PF 1KV C0G/NP0 1210 |
1,345 |
|
Datasheet |
CGA | Tape & Reel (TR) | Active | 3900 pF | ±5% | 1000V (1kV) | C0G, NP0 | -55°C ~ 125°C | High Voltage | AEC-Q200 | Automotive, SMPS Filtering | - | Surface Mount, MLCC | 1210 (3225 Metric) | 0.126" L x 0.098" W (3.20mm x 2.50mm) | - | 0.087" (2.20mm) | - | - |
|
|
C1808C471KGRACTUCAP CER 470PF 2KV X7R 1808 |
1,123 |
|
Datasheet |
SMD Comm X7R HV | Tape & Reel (TR) | Active | 470 pF | ±10% | 2000V (2kV) | X7R | -55°C ~ 125°C | Low ESL, High Voltage | - | General Purpose | - | Surface Mount, MLCC | 1808 (4520 Metric) | 0.185" L x 0.079" W (4.70mm x 2.00mm) | - | 0.069" (1.75mm) | - | - |
|
|
1812AA821JAT2ACAP CER 820PF 1KV C0G/NP0 1812 |
645 |
|
Datasheet |
KGM - HV | Tape & Reel (TR) | Active | 820 pF | ±5% | 1000V (1kV) | C0G, NP0 | -55°C ~ 125°C | High Voltage | - | General Purpose | - | Surface Mount, MLCC | 1812 (4532 Metric) | 0.181" L x 0.126" W (4.60mm x 3.20mm) | - | 0.087" (2.21mm) | - | - |
|
|
C1210C331JBGACTUCAP CER 330PF 630V C0G/NP0 1210 |
463 |
|
Datasheet |
SMD Comm C0G HV | Tape & Reel (TR) | Active | 330 pF | ±5% | 630V | C0G, NP0 | -55°C ~ 125°C | Low ESL, High Voltage | - | General Purpose | - | Surface Mount, MLCC | 1210 (3225 Metric) | 0.126" L x 0.098" W (3.20mm x 2.50mm) | - | 0.055" (1.40mm) | - | - |
-2.3.jpg)
|
CGA9N2X7R2A155M230KACAP CER 1.5UF 100V X7R 2220 |
142 |
|
Datasheet |
CGA | Tape & Reel (TR) | Not For New Designs | 1.5 µF | ±20% | 100V | X7R | -55°C ~ 125°C | - | AEC-Q200 | Automotive | - | Surface Mount, MLCC | 2220 (5750 Metric) | 0.224" L x 0.197" W (5.70mm x 5.00mm) | - | 0.098" (2.50mm) | - | - |
-2,30mm.jpg)
|
GRM43DR73A333KW01KCAP CER 0.033UF 1KV X7R 1812 |
5,660 |
|
Datasheet |
GRM | Tape & Reel (TR) | Active | 0.033 µF | ±10% | 1000V (1kV) | X7R | -55°C ~ 125°C | - | - | General Purpose | - | Surface Mount, MLCC | 1812 (4532 Metric) | 0.177" L x 0.126" W (4.50mm x 3.20mm) | - | 0.079" (2.00mm) | - | - |
-1,50mm.jpg)
|
GRJ43QR72J683KWJ1KCAP CER 0.068UF 630V X7R 1812 |
5,428 |
|
Datasheet |
GRJ | Tape & Reel (TR) | Active | 0.068 µF | ±10% | 630V | X7R | -55°C ~ 125°C | Soft Termination | - | Boardflex Sensitive | - | Surface Mount, MLCC | 1812 (4532 Metric) | 0.177" L x 0.126" W (4.50mm x 3.20mm) | - | 0.059" (1.50mm) | - | - |
|
|
600S430FW250XT4KCAP CER 43PF 250V NP0 0603 |
3,475 |
|
Datasheet |
ATC 600S | Tape & Reel (TR) | Active | 43 pF | ±1% | 250V | C0G, NP0 | -55°C ~ 125°C | High Q, Low Loss, Ultra Low ESR | - | RF, Microwave, High Frequency, Bypass, Decoupling | - | Surface Mount, MLCC | 0603 (1608 Metric) | 0.063" L x 0.032" W (1.60mm x 0.81mm) | - | 0.035" (0.89mm) | - | - |
|
GR332DD72W683KW01KCAP CER 0.068UF 450V X7T 1210 |
3,252 |
|
Datasheet |
GR3 | Tape & Reel (TR) | Active | 0.068 µF | ±10% | 450V | X7T | -55°C ~ 125°C | - | - | General Purpose | - | Surface Mount, MLCC | 1210 (3225 Metric) | 0.126" L x 0.098" W (3.20mm x 2.50mm) | - | 0.079" (2.00mm) | - | - |
