Film Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Capacitance | Tolerance | Voltage Rating - AC | Voltage Rating - DC | Dielectric Material | ESR (Equivalent Series Resistance) | Operating Temperature | Mounting Type | Size / Dimension | Height - Seated (Max) | Termination | Lead Spacing | Applications | Ratings | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
BFC237342225CAP FILM 2.2UF 5% 250VDC RADIAL |
9,911 |
|
Datasheet |
Radial | 2.2 µF | ±5% | 160V | 250V | Polyester, Metallized | - | -55°C ~ 105°C | Through Hole | 1.024" L x 0.394" W (26.00mm x 10.00mm) | 0.768" (19.50mm) | PC Pins | 0.886" (22.50mm) | General Purpose | - | Long Life |
|
|
BFC238362203CAP FILM 0.02UF 5% 2KVDC RADIAL |
4,817 |
|
Datasheet |
Radial | 0.02 µF | ±5% | 700V | 2000V (2kV) | Polypropylene (PP), Metallized | - | -55°C ~ 105°C | Through Hole | 1.024" L x 0.394" W (26.00mm x 10.00mm) | 0.768" (19.50mm) | PC Pins | 0.886" (22.50mm) | High Pulse, DV/DT | - | - |
|
C4CAWUC3150AA1JCAP FILM 0.15UF 5% 2KVDC AXIAL |
8,351 |
|
Datasheet |
Axial | 0.15 µF | ±5% | 630V | 2000V (2kV) | Polypropylene (PP), Metallized | 11.3 mOhms | -40°C ~ 85°C | Through Hole | 0.768" Dia x 1.732" L (19.50mm x 44.00mm) | - | PC Pins | - | Snubber | - | - |
|
F872FT105M480ZCAP FILM POLYPROP RAD X1 |
9,306 |
|
Datasheet |
Radial | 1 µF | ±20% | 480V | 1000V (1kV) | Polypropylene (PP), Metallized | - | -40°C ~ 110°C | Through Hole | 1.240" L x 1.220" W (31.50mm x 31.00mm) | 0.748" (19.00mm) | PC Pins | 1.083" (27.50mm) | EMI, RFI Suppression | X1 | - |
|
|
F871RW255J330Z2.50UF 330V |
3,476 |
|
- |
Radial | 2.5 µF | ±5% | 330V | 1000V (1kV) | Polypropylene (PP), Metallized | - | -40°C ~ 110°C | Through Hole | 1.614" L x 0.945" W (41.00mm x 24.00mm) | 0.748" (19.00mm) | PC Pins | 1.476" (37.50mm) | EMI, RFI Suppression | X1 | - |
|
|
MKS4C052706B00MJ00CAP FILM 27UF 20% 63VDC RADIAL |
3,464 |
|
Datasheet |
Radial | 27 µF | ±20% | 40V | 63V | Polyester, Polyethylene Terephthalate (PET), Metallized | - | -55°C ~ 125°C | Through Hole | 1.240" L x 0.433" W (31.50mm x 11.00mm) | 0.827" (21.00mm) | PC Pins | 1.083" (27.50mm) | Automotive; DC Link, DC Filtering | AEC-Q200 | - |
|
|
MKS4C052706B00MH00CAP FILM 27UF 20% 63VDC RADIAL |
4,894 |
|
Datasheet |
Radial | 27 µF | ±20% | 40V | 63V | Polyester, Polyethylene Terephthalate (PET), Metallized | - | -55°C ~ 125°C | Through Hole | 1.240" L x 0.433" W (31.50mm x 11.00mm) | 0.827" (21.00mm) | PC Pins | 1.083" (27.50mm) | Automotive; DC Link, DC Filtering | AEC-Q200 | - |
|
|
R75TW3470AA30JCAP FILM AUTO POLYPROP RAD |
4,075 |
|
Datasheet |
Radial | 0.47 µF | ±5% | 650V | 1600V (1.6kV) | Polypropylene (PP), Metallized | - | -55°C ~ 105°C | Through Hole | 1.634" L x 0.630" W (41.50mm x 16.00mm) | 1.126" (28.60mm) | PC Pins | 1.476" (37.50mm) | High Frequency, Switching; High Pulse, DV/DT | - | - |
|
|
F861FT395K310ZCAP FILM POLYPROP RAD X2 |
3,695 |
|
Datasheet |
Radial | 3.9 µF | ±10% | 310V | 630V | Polypropylene (PP), Metallized | - | -40°C ~ 110°C | Through Hole | 1.240" L x 1.220" W (31.50mm x 31.00mm) | 0.748" (19.00mm) | PC Pins | 1.083" (27.50mm) | EMI, RFI Suppression | X2 | - |
|
MKP1848C58050JK2CAP FILM 8UF 5% 500VDC RADIAL |
4,252 |
|
Datasheet |
Radial | 8 µF | ±5% | - | 500V | Polypropylene (PP), Metallized | 12 mOhms | -55°C ~ 105°C | Through Hole | 1.260" L x 0.591" W (32.00mm x 15.00mm) | 0.984" (25.00mm) | PC Pins | 1.083" (27.50mm) | DC Link, DC Filtering | - | Low ESR; Low ESL; Long Life |
|
|
MKP1845410104RCAP FILM 0.1UF 5% 1KVDC AXIAL |
8,176 |
|
Datasheet |
Axial | 0.1 µF | ±5% | 600V | 1000V (1kV) | Polypropylene (PP), Metallized | - | -55°C ~ 100°C | Through Hole | 0.610" Dia x 1.339" L (15.50mm x 34.00mm) | - | PC Pins | - | DC Link, DC Filtering; High Pulse, DV/DT; Snubber | - | - |
|
|
R75IW4820AA40JCAP FILM AUTO POLYPROP RAD |
2,123 |
|
Datasheet |
Radial | 8.2 µF | ±5% | 160V | 250V | Polypropylene (PP), Metallized | 5.8 mOhms | -55°C ~ 105°C | Through Hole | 1.634" L x 0.630" W (41.50mm x 16.00mm) | 1.126" (28.60mm) | PC Pins | 1.476" (37.50mm) | High Frequency, Switching; High Pulse, DV/DT | - | - |
|
|
BFC237521104CAP FILM 0.1UF 3.5% 1KVDC RADIAL |
8,089 |
|
Datasheet |
Radial | 0.1 µF | ±3.5% | 400V | 1000V (1kV) | Polypropylene (PP), Metallized | - | -55°C ~ 105°C | Through Hole | 1.181" L x 0.413" W (30.00mm x 10.50mm) | 0.925" (23.50mm) | PC Pins | 0.394" (10.00mm) | High Pulse, DV/DT | - | - |
|
|
BFC238364273CAP FILM 0.027UF 5% 2KVDC RADIAL |
8,076 |
|
Datasheet |
Radial | 0.027 µF | ±5% | 700V | 2000V (2kV) | Polypropylene (PP), Metallized | - | -55°C ~ 105°C | Through Hole | 1.220" L x 0.433" W (31.00mm x 11.00mm) | 0.827" (21.00mm) | PC Pins | 1.083" (27.50mm) | High Pulse, DV/DT | - | - |
|
|
F872FT684K480ZCAP FILM POLYPROP RAD X1 |
6,115 |
|
Datasheet |
Radial | 0.68 µF | ±10% | 480V | 1000V (1kV) | Polypropylene (PP), Metallized | - | -40°C ~ 110°C | Through Hole | 1.240" L x 1.220" W (31.50mm x 31.00mm) | 0.748" (19.00mm) | PC Pins | 1.083" (27.50mm) | EMI, RFI Suppression | X1 | - |
|
QAP2E105KRPCAP FILM 1UF 10% 250VDC AXIAL |
10 |
|
Datasheet |
Axial | 1 µF | ±10% | - | 250V | Polypropylene (PP), Metallized | - | -40°C ~ 85°C | Through Hole | 0.638" W, 0.315" T x 1.181" L (16.20mm, 8.00mm x 30.00mm) | - | PC Pins | - | High Frequency, Switching | - | - |
|
|
C4AEHBU4700A1YJCAP FILM METAL RAD POLYPROP |
4,347 |
|
Datasheet |
Radial | 7 µF | ±5% | - | 600V | Polypropylene (PP), Metallized | 9 mOhms | -40°C ~ 105°C | Through Hole | 1.240" L x 0.551" W (31.50mm x 14.00mm) | 1.110" (28.20mm) | PC Pins | 1.083" (27.50mm) | DC Link, DC Filtering; High Frequency, Switching | - | - |
|
|
EFPLS1AJ474E042LHCAP FILM 0.47UF 5% 1000VDC RAD |
9,391 |
|
Datasheet |
Radial | 0.47 µF | ±5% | - | 1000V (1kV) | Polypropylene (PP), Metallized | 11 mOhms | -40°C ~ 105°C | Through Hole | 1.654" L x 0.669" W (42.00mm x 17.00mm) | 1.142" (29.00mm) | PC Pins | 1.476" (37.50mm) | High Frequency, Switching; High Pulse, DV/DT | - | - |
|
|
EFPLS1AJ564E042LHCAP FILM 0.56UF 5% 1000VDC RAD |
7,913 |
|
Datasheet |
Radial | 0.56 µF | ±5% | - | 1000V (1kV) | Polypropylene (PP), Metallized | 10.5 mOhms | -40°C ~ 105°C | Through Hole | 1.654" L x 0.669" W (42.00mm x 17.00mm) | 1.142" (29.00mm) | PC Pins | 1.476" (37.50mm) | High Frequency, Switching; High Pulse, DV/DT | - | - |
|
|
EFPLS1AJ394E042LHCAP FILM 0.39UF 5% 1000VDC RAD |
9,392 |
|
Datasheet |
Radial | 0.39 µF | ±5% | - | 1000V (1kV) | Polypropylene (PP), Metallized | 11.5 mOhms | -40°C ~ 105°C | Through Hole | 1.654" L x 0.669" W (42.00mm x 17.00mm) | 1.142" (29.00mm) | PC Pins | 1.476" (37.50mm) | High Frequency, Switching; High Pulse, DV/DT | - | - |
