Aluminum Electrolytic Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Polarization | Ratings | Applications | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
30D226M040BB5ACAP ALUM 22UF 20% 40V AXIAL TH |
0 |
|
Datasheet |
30D | Bulk | Active | 22 µF | ±20% | 40 V | 11.7Ohm @ 120Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 81 mA @ 120 Hz | 113.4 mA @ 100 kHz | - | - | 0.248" Dia x 0.689" L (6.30mm x 17.50mm) | - | - | Through Hole | |
|
500D107M025CC2TCAP ALUM 100UF 20% 25V AXIAL TH |
0 |
|
Datasheet |
500D | Bulk | Active | 100 µF | ±20% | 25 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | - | General Purpose | - | - | - | - | 0.315" Dia x 0.807" L (8.00mm x 20.50mm) | - | - | Through Hole | |
|
|
500D256G050CC2TCAP ALUM 25UF 50V AXIAL TH |
0 |
|
Datasheet |
500D | Bulk | Active | 25 µF | - | 50 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | - | General Purpose | - | - | - | - | 0.315" Dia x 0.807" L (8.00mm x 20.50mm) | - | - | Through Hole | |
|
500D476M025BB5ACAP ALUM 47UF 20% 25V AXIAL TH |
0 |
|
Datasheet |
500D | Bulk | Active | 47 µF | ±20% | 25 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | - | General Purpose | - | - | - | - | 0.248" Dia x 0.689" L (6.30mm x 17.50mm) | - | - | Through Hole | |
|
TE1204ECAP ALUM 10UF 25V AXIAL TH |
0 |
|
Datasheet |
TE | Bulk | Active | 10 µF | -10%, +75% | 25 V | - | 2000 Hrs @ 85°C | -40°C ~ 105°C | Polar | - | General Purpose | - | - | - | - | 0.248" Dia x 0.689" L (6.30mm x 17.50mm) | - | - | Through Hole | |
|
|
TE1303ECAP ALUM 5UF 50V AXIAL TH |
0 |
|
Datasheet |
TE | Bulk | Active | 5 µF | -10%, +75% | 50 V | - | 2000 Hrs @ 85°C | -40°C ~ 105°C | Polar | - | General Purpose | - | - | - | - | 0.248" Dia x 0.689" L (6.30mm x 17.50mm) | - | - | Through Hole | |
|
|
TE1501ECAP ALUM 2UF 150V AXIAL TH |
0 |
|
Datasheet |
TE | Bulk | Active | 2 µF | -10%, +50% | 150 V | - | 2000 Hrs @ 85°C | -40°C ~ 105°C | Polar | - | General Purpose | - | - | - | - | 0.248" Dia x 0.689" L (6.30mm x 17.50mm) | - | - | Through Hole | |
|
B43640A5157M002CAP ALUM 150UF 20% 450V SNAP TH |
0 |
|
Datasheet |
B43640 | Bulk | Active | 150 µF | ±20% | 450 V | 630mOhm @ 100Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 850 mA @ 100 Hz | - | - | 0.394" (10.00mm) | 0.866" Dia (22.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
|
RLD121M2WBK-1845SCAP ALUM 450V POLAR |
0 |
|
- |
RLD | Active | 120 µF | ±20% | 450 V | - | 12000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 945 mA @ 120 Hz | 2.126 A @ 100 kHz | - | 0.295" (7.50mm) | 0.709" Dia (18.00mm) | 1.850" (47.00mm) | - | Through Hole | ||
|
LKG1V152MESYCKCAP ALUM 1500UF 20% 35V SNAP TH |
0 |
|
Datasheet |
LKG | Bulk | Obsolete | 1500 µF | ±20% | 35 V | - | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | Audio | 1.55 A @ 120 Hz | - | - | 0.394" (10.00mm) | 0.787" Dia (20.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
25MXC18000MEFCSN30X30CAP ALUM 18000UF 20% 25V SNAP TH |
0 |
|
Datasheet |
MXC | Bulk | Not For New Designs | 18000 µF | ±20% | 25 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3.56 A @ 120 Hz | 4.094 A @ 10 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
|
LSM122M2C---3530SCAP ALUM 160V POLAR |
0 |
|
- |
LSM | Active | 1.2 mF | ±20% | 160 V | 166mOhm @ 120Hz | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 2.29 A @ 120 Hz | 3.206 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.260" (32.00mm) | - | Through Hole | ||
|
ESMR421VSN331MA25SCAP ALUM 330UF 20% 420V SNAP TH |
0 |
|
Datasheet |
SMR | Bulk | Active | 330 µF | ±20% | 420 V | - | 2000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 1.99 A @ 120 Hz | 2.8457 A @ 50 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.083" (27.50mm) | - | Through Hole | |
|
|
LSK271M2G---2545SCAP ALUM 400V POLAR |
0 |
|
- |
LSK | Active | 270 µF | ±20% | 400 V | 737mOhm @ 120Hz | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.06 A @ 120 Hz | 1.484 A @ 10 kHz | - | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.850" (47.00mm) | - | Through Hole | ||
|
UKT1V682MRDCAP ALUM 6800UF 20% 35V RADIAL |
0 |
|
Datasheet |
UKT | Bulk | Obsolete | 6800 µF | ±20% | 35 V | - | 1000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | Audio | 2.15 A @ 120 Hz | 2.473 A @ 10 kHz | - | 0.394" (10.00mm) | 0.787" Dia (20.00mm) | 1.634" (41.50mm) | - | Through Hole | |
|
|
ELH478M080AS4AACAP ALUM SNAP-IN 85C |
0 |
|
Datasheet |
ELH | Bulk | Active | 4.7 mF | ±20% | 80 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 4.05 A @ 120 Hz | 4.698 A @ 10 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
380LX102M100K202CAP ALUM 1000UF 20% 100V SNAP TH |
0 |
|
Datasheet |
380LX | Bulk | Obsolete | 1000 µF | ±20% | 100 V | 250mOhm | 3000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 1.2 A @ 120 Hz | - | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 0.866" (22.00mm) | - | Through Hole | |
|
380LX181M400K022CAP ALUM 180UF 20% 400V SNAP TH |
0 |
|
Datasheet |
380LX | Bulk | Obsolete | 180 µF | ±20% | 400 V | 1.105Ohm @ 120Hz | 3000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 1.4 A @ 120 Hz | 2 A @ 20 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
380LX332M063A202CAP ALUM 3300UF 20% 63V SNAP TH |
0 |
|
Datasheet |
380LX | Bulk | Obsolete | 3300 µF | ±20% | 63 V | 125mOhm | 3000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 1.7 A @ 120 Hz | - | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 0.866" (22.00mm) | - | Through Hole | |
|
381LR561M200J022CAP ALUM 560UF 20% 200V SNAP TH |
0 |
|
Datasheet |
381LR | Bulk | Obsolete | 560 µF | ±20% | 200 V | 266mOhm @ 120Hz | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.14 A @ 120 Hz | 3.05 A @ 20 kHz | - | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.260" (32.00mm) | - | Through Hole |
