Aluminum Electrolytic Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Polarization | Ratings | Applications | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
500D106M150DC2E3CAP ALUM 10UF 20% 150V AXIAL TH |
0 |
|
Datasheet |
500D | Bulk | Active | 10 µF | ±20% | 150 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | - | General Purpose | - | - | - | - | 0.374" Dia x 0.807" L (9.50mm x 20.50mm) | - | - | Through Hole | |
|
TVA1405-E3CAP ALUM 8UF 150V AXIAL TH |
0 |
|
Datasheet |
TVA ATOM® | Bulk | Active | 8 µF | - | 150 V | - | - | -20°C ~ 85°C | Polar | - | Audio | - | - | - | - | 0.375" Dia x 0.812" L (9.52mm x 20.62mm) | - | - | Through Hole | |
|
|
TE1407-E3CAP ALUM 10UF 100V AXIAL TH |
0 |
|
Datasheet |
TE | Bulk | Active | 10 µF | -10%, +50% | 100 V | - | 2000 Hrs @ 85°C | -40°C ~ 105°C | Polar | - | General Purpose | - | - | - | - | 0.354" Dia x 0.807" L (9.00mm x 20.50mm) | - | - | Through Hole | |
|
ELXS251VSN561MP45SCAP ALUM 560UF 20% 250V SNAP TH |
0 |
|
Datasheet |
LXS | Bulk | Active | 560 µF | ±20% | 250 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.79 A @ 120 Hz | 2.685 A @ 50 kHz | - | 0.394" (10.00mm) | 0.866" Dia (22.00mm) | 1.870" (47.50mm) | - | Through Hole | |
|
ELXM251VSN471MP50SCAP ALUM 470UF 20% 250V SNAP TH |
0 |
|
Datasheet |
LXM | Bulk | Active | 470 µF | ±20% | 250 V | - | 7000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.49 A @ 120 Hz | 2.235 A @ 50 kHz | - | 0.394" (10.00mm) | 0.866" Dia (22.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
B43254B5127M000CAP ALUM 120UF 20% 450V SNAP TH |
0 |
|
Datasheet |
B43254 | Bulk | Not For New Designs | 120 µF | ±20% | 450 V | - | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 500 mA @ 120 Hz | 775 mA @ 20 kHz | - | 0.394" (10.00mm) | 1.000" Dia (25.40mm) | 1.260" (32.00mm) | - | Through Hole | |
|
MAL214631182E3CAP ALUM 1800UF 20% 50V RADIAL |
0 |
|
Datasheet |
146 RTI | Tape & Box (TB) | Active | 1800 µF | ±20% | 50 V | - | 6000 Hrs @ 125°C | -55°C ~ 125°C | Polar | AEC-Q200 | Automotive | - | 2.7 A @ 100 kHz | 26 mOhms | 0.295" (7.50mm) | 0.709" Dia (18.00mm) | 1.319" (33.50mm) | - | Through Hole | |
|
|
MAL214635682E3CAP ALUM 6800UF 20% 16V RADIAL |
0 |
|
Datasheet |
146 RTI | Tape & Box (TB) | Active | 6800 µF | ±20% | 16 V | - | 6000 Hrs @ 125°C | -55°C ~ 125°C | Polar | AEC-Q200 | Automotive | - | 3.1 A @ 100 kHz | 22 mOhms | 0.295" (7.50mm) | 0.709" Dia (18.00mm) | 1.319" (33.50mm) | - | Through Hole | |
|
|
MAL214638102E3CAP ALUM 1000UF 20% 63V RADIAL |
0 |
|
Datasheet |
146 RTI | Tape & Box (TB) | Active | 1000 µF | ±20% | 63 V | - | 6000 Hrs @ 125°C | -55°C ~ 125°C | Polar | AEC-Q200 | Automotive | - | 2.4 A @ 100 kHz | 32 mOhms | 0.295" (7.50mm) | 0.709" Dia (18.00mm) | 1.319" (33.50mm) | - | Through Hole | |
|
|
MAL214690273E3CAP ALUM 2700UF 20% 35V RADIAL |
0 |
|
Datasheet |
146 RTI | Tape & Box (TB) | Active | 2700 µF | ±20% | 35 V | - | 6000 Hrs @ 125°C | -55°C ~ 125°C | Polar | AEC-Q200 | Automotive | - | 3.1 A @ 100 kHz | 22 mOhms | 0.295" (7.50mm) | 0.709" Dia (18.00mm) | 1.319" (33.50mm) | - | Through Hole | |
|
|
MAL214696473E3CAP ALUM 4700UF 20% 25V RADIAL |
0 |
|
Datasheet |
146 RTI | Tape & Box (TB) | Active | 4700 µF | ±20% | 25 V | - | 6000 Hrs @ 125°C | -55°C ~ 125°C | Polar | AEC-Q200 | Automotive | - | 3.1 A @ 100 kHz | 22 mOhms | 0.295" (7.50mm) | 0.709" Dia (18.00mm) | 1.319" (33.50mm) | - | Through Hole | |
|
107LBB400M2BDCAP ALUM 100UF 20% 400V SNAP TH |
0 |
|
Datasheet |
LBB | Bulk | Active | 100 µF | ±20% | 400 V | 2.4868Ohm @ 120Hz | 3000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 910 mA @ 120 Hz | 1.3377 A @ 10 kHz | - | 0.394" (10.00mm) | 0.866" Dia (22.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
|
478LMB063M2CHCAP ALUM 4700UF 20% 63V SNAP TH |
0 |
|
Datasheet |
LMB | Bulk | Active | 4700 µF | ±20% | 63 V | 105.821mOhm @ 120Hz | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.93 A @ 120 Hz | 3.663 A @ 10 kHz | - | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
|
B43642A9157M000CAP ALUM 150UF 20% 400V SNAP TH |
0 |
|
Datasheet |
B43642 | Bulk | Active | 150 µF | ±20% | 400 V | 660mOhm @ 100Hz | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 800 mA @ 100 Hz | - | - | 0.394" (10.00mm) | 0.866" Dia (22.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
MAL212518102E3CAP ALUM 1000UF 20% 63V AXIAL TH |
0 |
|
- |
125 ALS | Box | Active | 1000 µF | ±20% | 63 V | 133mOhm @ 100Hz | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1 A @ 100 Hz | 1.4 A @ 10 kHz | 120 mOhms | - | 0.709" Dia x 1.496" L (18.00mm x 38.00mm) | - | - | Through Hole | |
|
MAL212514822E3CAP ALUM 8200UF 20% 10V AXIAL TH |
0 |
|
- |
125 ALS | Box | Active | 8200 µF | ±20% | 10 V | 56mOhm @ 100Hz | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.35 A @ 100 Hz | 1.62 A @ 10 kHz | 110 mOhms | - | 0.709" Dia x 1.181" L (18.00mm x 30.00mm) | - | - | Through Hole | |
|
|
MAL212516392E3CAP ALUM 3900UF 20% 25V AXIAL TH |
0 |
|
- |
125 ALS | Box | Active | 3900 µF | ±20% | 25 V | 68mOhm @ 100Hz | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.3 A @ 100 Hz | 1.69 A @ 10 kHz | 100 mOhms | - | 0.709" Dia x 1.496" L (18.00mm x 38.00mm) | - | - | Through Hole | |
|
|
MAL212515562E3CAP ALUM 5600UF 20% 16V AXIAL TH |
0 |
|
Datasheet |
125 ALS | Box | Active | 5600 µF | ±20% | 16 V | 62mOhm @ 100Hz | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.28 A @ 100 Hz | 1.664 A @ 10 kHz | 100 mOhms | - | 0.709" Dia x 1.181" L (18.00mm x 30.00mm) | - | - | Through Hole | |
|
|
MAL212517152E3CAP ALUM 1500UF 20% 40V AXIAL TH |
0 |
|
Datasheet |
125 ALS | Box | Active | 1500 µF | ±20% | 40 V | 106mOhm @ 100Hz | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.15 A @ 100 Hz | 1.61 A @ 10 kHz | 98 mOhms | - | 0.709" Dia x 1.181" L (18.00mm x 30.00mm) | - | - | Through Hole | |
|
|
MAL212515682E3CAP ALUM 6800UF 20% 16V AXIAL TH |
0 |
|
- |
125 ALS | Box | Active | 6800 µF | ±20% | 16 V | 55mOhm @ 100Hz | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.31 A @ 100 Hz | 1.703 A @ 10 kHz | 100 mOhms | - | 0.709" Dia x 1.496" L (18.00mm x 38.00mm) | - | - | Through Hole |
