Aluminum Electrolytic Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Polarization | Ratings | Applications | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MAL205956689E3CAP ALUM 68UF 20% 400V SNAP TH |
0 |
|
Datasheet |
059 PLL-SI | Tape & Box (TB) | Active | 68 µF | ±20% | 400 V | 2.95Ohm @ 100Hz | 10000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 410 mA @ 100 Hz | - | 2.42 Ohms | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
|
MAL205972221E3CAP ALUM 220UF 20% 200V SNAP TH |
0 |
|
Datasheet |
059 PLL-SI | Tape & Box (TB) | Active | 220 µF | ±20% | 200 V | 610mOhm @ 100Hz | 10000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 870 mA @ 100 Hz | - | 430 mOhms | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
MAL205976689E3CAP ALUM 68UF 20% 400V SNAP TH |
0 |
|
Datasheet |
059 PLL-SI | Tape & Box (TB) | Active | 68 µF | ±20% | 400 V | 2.95Ohm @ 100Hz | 10000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 410 mA @ 100 Hz | - | 2.42 Ohms | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
MAL215717101E3CAP ALUM 100UF 20% 450V SNAP TH |
0 |
|
Datasheet |
157 PUM-SI | Bulk | Active | 100 µF | ±20% | 450 V | 2Ohm @ 100Hz | 5000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 1 A @ 120 Hz | - | 1.05 Ohms | 0.394" (10.00mm) | 0.866" Dia (22.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
MAL215737101E3CAP ALUM 100UF 20% 450V SNAP TH |
0 |
|
Datasheet |
157 PUM-SI | Bulk | Active | 100 µF | ±20% | 450 V | 2Ohm @ 100Hz | 5000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 1 A @ 120 Hz | - | 1.05 Ohms | 0.394" (10.00mm) | 0.866" Dia (22.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
|
MAL215757101E3CAP ALUM 100UF 20% 450V SNAP TH |
0 |
|
Datasheet |
157 PUM-SI | Bulk | Active | 100 µF | ±20% | 450 V | 2Ohm @ 100Hz | 5000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 1.02 A @ 120 Hz | - | 1.05 Ohms | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
|
MAL215777101E3CAP ALUM 100UF 20% 450V SNAP TH |
0 |
|
Datasheet |
157 PUM-SI | Bulk | Active | 100 µF | ±20% | 450 V | 2Ohm @ 100Hz | 5000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 1.02 A @ 120 Hz | - | 1.05 Ohms | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
PEH228KKP4170QE4CAP ALUM 1700UF 40V SOLDER LUG |
0 |
|
Datasheet |
PEH228 | Tray | Active | 1700 µF | -10%, +30% | 40 V | 54mOhm @ 100Hz | 1500 Hrs @ 150°C | -40°C ~ 150°C | Polar | AEC-Q200 | Automotive | 2.52 A @ 100 Hz | 7.2 A @ 5 kHz | - | 0.600" (15.24mm) | 0.638" Dia (16.20mm) | 1.445" (36.70mm) | - | Through Hole | |
|
400HXC220MEFCSN30X35CAP ALUM 220UF 20% 400V SNAP TH |
0 |
|
Datasheet |
HXC | Bulk | Active | 220 µF | ±20% | 400 V | - | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.84 A @ 120 Hz | 2.576 A @ 10 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
MAL225989121E3CAP ALUM 120UF 20% 500V SNAP TH |
0 |
|
- |
259 PHM-SI | Box | Active | 120 µF | ±20% | 500 V | 1.2Ohm @ 100Hz | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.16 A @ 100 Hz | 1.74 A @ 10 kHz | 920 mOhms | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.063" (27.00mm) | - | Through Hole | |
|
|
MAL225949121E3CAP ALUM 120UF 20% 500V SNAP TH |
0 |
|
- |
259 PHM-SI | Box | Active | 120 µF | ±20% | 500 V | 1.2Ohm @ 100Hz | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.16 A @ 100 Hz | 1.74 A @ 10 kHz | 920 mOhms | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.063" (27.00mm) | - | Through Hole | |
|
ALC70A561CF350CAP ALUM 560UF 20% 350V SNAP TH |
0 |
|
Datasheet |
ALC70 | Bulk | Active | 560 µF | ±20% | 350 V | 249mOhm @ 100Hz | 13000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 2.46 A @ 100 Hz | 6.11 A @ 10 kHz | 129 mOhms | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
|
ALC70D561CF350CAP ALUM 560UF 20% 350V SNAP TH |
0 |
|
Datasheet |
ALC70 | Bulk | Active | 560 µF | ±20% | 350 V | 249mOhm @ 100Hz | 13000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 2.46 A @ 100 Hz | 6.11 A @ 10 kHz | 129 mOhms | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
ALC70F561CF350CAP ALUM 560UF 20% 350V SNAP TH |
0 |
|
Datasheet |
ALC70 | Bulk | Active | 560 µF | ±20% | 350 V | 249mOhm @ 100Hz | 13000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 2.46 A @ 100 Hz | 6.11 A @ 10 kHz | 129 mOhms | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
|
ALC40D471DE400CAP ALUM SNAP-IN 105C |
0 |
|
Datasheet |
ALC40 | Box | Active | 470 µF | ±20% | 400 V | 300mOhm @ 100Hz | 8000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.5 A @ 100 Hz | 4.73 A @ 10 kHz | 192 mOhms | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.850" (47.00mm) | - | Through Hole | |
|
ALA8DA361CD400CAP ALUM 360UF 20% 400V SNAP TH |
0 |
|
Datasheet |
ALA8D | Bulk | Active | 360 µF | ±20% | 400 V | 420.4mOhm @ 100Hz | 7000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 1.66 A @ 100 Hz | 2.91 A @ 10 kHz | 692.8 mOhms | - | 1.181" Dia (30.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
ERLA251LIN122KA45MCAP ALUM 1200UF 10% 250V SNAP TH |
0 |
|
Datasheet |
RLA | Bulk | Active | 1200 µF | ±10% | 250 V | - | 3000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 5.68 A @ 120 Hz | 8.52 A @ 50 kHz | - | 0.559" (14.20mm) | 1.378" Dia (35.00mm) | 1.870" (47.50mm) | - | Through Hole | |
|
ELHS4H1VSN391MR50SCAP ALUM 390UF 20% 475V SNAP TH |
0 |
|
Datasheet |
LHS | Bulk | Active | 390 µF | ±20% | 475 V | - | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.8 A @ 120 Hz | 2.574 A @ 50 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 2.067" (52.50mm) | - | Through Hole | |
|
|
B43643A5337M057CAP ALUM 330UF 20% 450V SNAP TH |
0 |
|
Datasheet |
B43643 | Bulk | Active | 330 µF | ±20% | 450 V | 330mOhm @ 100Hz | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.65 A @ 100 Hz | - | - | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.850" (47.00mm) | - | Through Hole | |
|
420VXG220MEFCSN35X25CAP ALUM 220UF 20% 420V SNAP TH |
0 |
|
Datasheet |
VXG | Bulk | Active | 220 µF | ±20% | 420 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.24 A @ 120 Hz | 1.736 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.063" (27.00mm) | - | Through Hole |
