Aluminum Electrolytic Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Polarization | Ratings | Applications | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ALA7DC471DD450CAP ALUM 470UF 20% 450V SNAP TH |
0 |
|
Datasheet |
ALA7D | Bulk | Active | 470 µF | ±20% | 450 V | 327mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive | 2.26 A @ 100 Hz | 6.01 A @ 10 kHz | 207.2 mOhms | - | 1.378" Dia (35.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
|
ALA8DC471DD400CAP ALUM 470UF 20% 400V SNAP TH |
0 |
|
Datasheet |
ALA8D | Bulk | Active | 470 µF | ±20% | 400 V | 327mOhm @ 100Hz | 7000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 2.42 A @ 100 Hz | 6.52 A @ 10 kHz | 186.4 mOhms | - | 1.378" Dia (35.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
|
ALA8DE471DD400CAP ALUM 470UF 20% 400V SNAP TH |
0 |
|
Datasheet |
ALA8D | Bulk | Active | 470 µF | ±20% | 400 V | 327mOhm @ 100Hz | 8000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 2.98 A @ 100 Hz | 7.41 A @ 10 kHz | 146.4 mOhms | - | 1.378" Dia (35.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
LAQ2P821MELB45CAP ALUM 820UF 20% 220V SNAP TH |
0 |
|
Datasheet |
LAQ | Bulk | Active | 820 µF | ±20% | 220 V | - | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 2.11 A @ 120 Hz | 2.532 A @ 10 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.850" (47.00mm) | - | Through Hole | |
|
ALC40C331EG450CAP ALUM SNAP-IN 105C |
0 |
|
Datasheet |
ALC40 | Box | Active | 330 µF | ±20% | 450 V | 293mOhm @ 100Hz | 9000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3.14 A @ 100 Hz | 7.29 A @ 10 kHz | 204 mOhms | 0.394" (10.00mm) | 1.575" Dia (40.00mm) | 2.244" (57.00mm) | - | Through Hole | |
|
|
MAL216255682E3CAP ALUM 6800UF 20% 16V SNAP TH |
0 |
|
Datasheet |
162 PLL-PW | Bulk | Active | 6800 µF | ±20% | 16 V | 50mOhm @ 100Hz | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3.11 A @ 100 Hz | - | 37 mOhms | - | 0.984" Dia (25.00mm) | 1.378" (35.00mm) | - | Through Hole | |
|
UKW1E153MRDCAP ALUM 15000UF 20% 25V RADIAL |
1 |
|
Datasheet |
UKW | Bulk | Obsolete | 15000 µF | ±20% | 25 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | Audio | 3.8 A @ 120 Hz | 4.37 A @ 10 kHz | - | 0.394" (10.00mm) | 0.866" Dia (22.00mm) | 1.969" (50.00mm) | - | Through Hole | |
|
UVK1V103MRDCAP ALUM 10000UF 20% 35V RADIAL |
1 |
|
Datasheet |
UVK | Bulk | Obsolete | 10000 µF | ±20% | 35 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 3.7 A @ 120 Hz | 4.255 A @ 10 kHz | - | 0.394" (10.00mm) | 0.866" Dia (22.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
|
400VXS180MEFC25X30CAP ALUM 180UF 20% 400V SNAP TH |
0 |
|
Datasheet |
VXS | Bulk | Discontinued at Digi-Key | 180 µF | ±20% | 400 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.2 A @ 120 Hz | 1.68 A @ 10 kHz | - | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
ELXM451VSN181MA30SCAP ALUM 180UF 20% 450V SNAP TH |
0 |
|
Datasheet |
LXM | Bulk | Active | 180 µF | ±20% | 450 V | - | 7000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.07 A @ 120 Hz | 1.5301 A @ 50 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
LP332M063H3P3CAP ALUM 3300UF 20% 63V SNAP TH |
0 |
|
Datasheet |
LP | Bulk | Active | 3300 µF | ±20% | 63 V | 76mOhm @ 120Hz | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.2 A @ 120 Hz | 2.64 A @ 100 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.181" (30.00mm) | - | Through Hole | |
|
380LX272M200A062CAP ALUM 2700UF 20% 200V SNAP TH |
0 |
|
Datasheet |
380LX | Bulk | Active | 2700 µF | ±20% | 200 V | 80mOhm @ 120Hz | 3000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 5.5 A @ 120 Hz | 7.7 A @ 20 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 2.559" (65.00mm) | - | Through Hole | |
|
381LX221M450A042CAP ALUM 220UF 20% 450V SNAP TH |
0 |
|
Datasheet |
381LX | Bulk | Active | 220 µF | ±20% | 450 V | 1.206Ohm @ 120Hz | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 900 mA @ 120 Hz | 1.3 A @ 20 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
MAL212327688CAP ALUM 6.8UF 20% 40V AXIAL TH |
0 |
|
Datasheet |
123 SAL-A | Tape & Reel (TR) | Obsolete | 6.8 µF | ±20% | 40 V | 35Ohm @ 100Hz | 20000 Hrs @ 125°C | -55°C ~ 125°C | Polar | - | General Purpose | 28 mA @ 100 Hz | - | 7.5 Ohms | - | 0.264" Dia x 0.602" L (6.70mm x 15.30mm) | - | - | Through Hole | |
|
|
MAL212327688E3CAP ALUM 6.8UF 20% 40V AXIAL TH |
0 |
|
Datasheet |
123 SAL-A | Tape & Reel (TR) | Obsolete | 6.8 µF | ±20% | 40 V | 35Ohm @ 100Hz | 20000 Hrs @ 125°C | -55°C ~ 125°C | Polar | - | General Purpose | 28 mA @ 100 Hz | - | 7.5 Ohms | - | 0.264" Dia x 0.602" L (6.70mm x 15.30mm) | - | - | Through Hole | |
|
MAL219377181E3CAP ALUM 180UF 20% 450V SNAP TH |
0 |
|
Datasheet |
193 PUR-SI | Box | Active | 180 µF | ±20% | 450 V | 480mOhm @ 100Hz | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.36 A @ 100 Hz | 2.04 A @ 10 kHz | 290 mOhms | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.063" (27.00mm) | - | Through Hole | |
|
MAL219337181E3CAP ALUM 180UF 20% 450V SNAP TH |
0 |
|
- |
193 PUR-SI | Box | Active | 180 µF | ±20% | 450 V | 480mOhm @ 100Hz | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.36 A @ 100 Hz | 2.04 A @ 10 kHz | 290 mOhms | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.063" (27.00mm) | - | Through Hole | |
|
|
350USC1000MEFC35X50CAP ALUM 1000UF 20% 350V SNAP TH |
0 |
|
Datasheet |
USC | Bulk | Not For New Designs | 1000 µF | ±20% | 350 V | - | 3000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 3.6 A @ 120 Hz | 5.04 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
450VXG330MEFC35X35CAP ALUM 330UF 20% 450V SNAP TH |
0 |
|
Datasheet |
VXG | Bulk | Active | 330 µF | ±20% | 450 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.65 A @ 120 Hz | 2.31 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
B43544A7227M082CAP ALUM 220UF 20% 550V SNAP TH |
0 |
|
Datasheet |
B43544 | Tray | Active | 220 µF | ±20% | 550 V | 530mOhm @ 100Hz | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.54 A @ 100 Hz | - | 830 mOhms | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 2.252" (57.20mm) | - | Through Hole |
