Aluminum Electrolytic Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Polarization | Ratings | Applications | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MAL215773391E3CAP ALUM 390UF 20% 250V SNAP TH |
0 |
|
Datasheet |
157 PUM-SI | Bulk | Active | 390 µF | ±20% | 250 V | 610mOhm @ 100Hz | 5000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 1.58 A @ 120 Hz | - | 425 mOhms | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.063" (27.00mm) | - | Through Hole | |
|
MAL215817472E3CAP ALUM 4700UF 20% 40V SNAP TH |
0 |
|
Datasheet |
158 PUL-SI | Bulk | Active | 4700 µF | ±20% | 40 V | 65mOhm @ 100Hz | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3.52 A @ 100 Hz | - | 51 mOhms | 0.394" (10.00mm) | 0.866" Dia (22.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
|
MAL215818152E3CAP ALUM 1500UF 20% 63V SNAP TH |
0 |
|
Datasheet |
158 PUL-SI | Bulk | Active | 1500 µF | ±20% | 63 V | 107mOhm @ 100Hz | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.49 A @ 100 Hz | - | 78 mOhms | 0.394" (10.00mm) | 0.866" Dia (22.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
|
MAL215857472E3CAP ALUM 4700UF 20% 40V SNAP TH |
0 |
|
Datasheet |
158 PUL-SI | Bulk | Active | 4700 µF | ±20% | 40 V | 65mOhm @ 100Hz | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3.52 A @ 100 Hz | - | 51 mOhms | 0.394" (10.00mm) | 0.866" Dia (22.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
|
MAL215858152E3CAP ALUM 1500UF 20% 63V SNAP TH |
0 |
|
Datasheet |
158 PUL-SI | Bulk | Active | 1500 µF | ±20% | 63 V | 107mOhm @ 100Hz | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.49 A @ 100 Hz | - | 78 mOhms | 0.394" (10.00mm) | 0.866" Dia (22.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
B43643C5397M057CAP ALUM 390UF 20% 450V SNAP TH |
0 |
|
Datasheet |
B43643 | Bulk | Active | 390 µF | ±20% | 450 V | 300mOhm @ 100Hz | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.49 A @ 100 Hz | - | 460 mOhms | 0.886" (22.50mm) | 1.378" Dia (35.00mm) | 1.280" (32.50mm) | - | Through Hole | |
|
672D127F100ET3DCAP ALUM 120UF 100V RADIAL TH |
0 |
|
Datasheet |
672D | Bulk | Active | 120 µF | -10%, +50% | 100 V | 680mOhm @ 120Hz | - | -55°C ~ 105°C | Polar | - | General Purpose | 825 mA @ 120 Hz | 1.5 A @ 100 kHz | 170 mOhms | 0.295" (7.50mm) | 0.630" Dia (16.00mm) | 1.417" (36.00mm) | - | Through Hole | |
|
|
B43642B6337M060CAP ALUM 500V POLAR |
0 |
|
Datasheet |
B43642 | Bulk | Active | 330 µF | ±20% | 500 V | 390mOhm @ 100Hz | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.79 A @ 100 Hz | - | 600 mOhms | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
400MXH470MEFCSN35X30CAP ALUM 470UF 20% 400V SNAP TH |
0 |
|
Datasheet |
MXH | Bulk | Active | 470 µF | ±20% | 400 V | - | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.68 A @ 120 Hz | 2.352 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
|
PEH228MLP4110QE4CAP ALUM 1100UF 63V SOLDER LUG |
0 |
|
Datasheet |
PEH228 | Tray | Active | 1100 µF | -10%, +30% | 63 V | 66mOhm @ 100Hz | 2000 Hrs @ 150°C | -40°C ~ 150°C | Polar | AEC-Q200 | Automotive | 2.31 A @ 100 Hz | 6.6 A @ 5 kHz | - | 0.600" (15.24mm) | 0.717" Dia (18.20mm) | 1.445" (36.70mm) | - | Through Hole | |
|
|
EKHS4H1VSN181MA25SCAP ALUM 180UF 20% 475V SNAP TH |
0 |
|
- |
KHS | Bulk | Active | 180 µF | ±20% | 475 V | - | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.08 A @ 120 Hz | 1.5444 A @ 50 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 0.984" (25.00mm) | - | Through Hole | |
|
|
B43541A7227M067CAP ALUM SNAP |
0 |
|
Datasheet |
* | Tray | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
ELXM161VSN222MA50SCAP ALUM 2200UF 20% 160V SNAP TH |
0 |
|
Datasheet |
LXM | Bulk | Active | 2200 µF | ±20% | 160 V | - | 7000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 3.87 A @ 120 Hz | 5.805 A @ 50 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
MAL211949221E3CAP ALUM 220UF 100V AXIAL TH |
0 |
|
Datasheet |
119 AHT-DIN | Tape & Reel (TR) | Active | 220 µF | -10%, +50% | 100 V | 720mOhm @ 100Hz | 8000 Hrs @ 125°C | -55°C ~ 125°C | Polar | - | General Purpose | 710 mA @ 100 Hz | - | 550 mOhms | - | 0.709" Dia (18.00mm) | 1.299" (33.00mm) | - | Through Hole | |
|
|
LSG681M2P---3550SCAP ALUM 420V POLAR |
0 |
|
- |
LSG | Active | 680 µF | ±20% | 420 V | 293mOhm @ 120Hz | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 2.12 A @ 120 Hz | 3.0316 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 2.047" (52.00mm) | - | Through Hole | ||
|
|
ALC40A102DD200CAP ALUM SNAP-IN 105C |
0 |
|
Datasheet |
ALC40 | Box | Active | 1 mF | ±20% | 200 V | 208mOhm @ 100Hz | 8000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.95 A @ 100 Hz | 2.69 A @ 10 kHz | 158 mOhms | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
400VXR390MEFCSN35X45CAP ALUM 390UF 20% 400V SNAP TH |
0 |
|
Datasheet |
VXR | Bulk | Not For New Designs | 390 µF | ±20% | 400 V | - | 7000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.3 A @ 120 Hz | 1.82 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.850" (47.00mm) | - | Through Hole | |
|
LGG2P152MELC35CAP ALUM 1500UF 20% 220V SNAP TH |
0 |
|
Datasheet |
LGG | Bulk | Active | 1500 µF | ±20% | 220 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.5 A @ 120 Hz | 3.75 A @ 50 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
ALF70C301DD500CAP ALUM 300UF 20% 500V PRESS |
0 |
|
Datasheet |
ALF70 | Bulk | Active | 300 µF | ±20% | 500 V | 674mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 1.97 A @ 100 Hz | 4.15 A @ 10 kHz | 478 mOhms | 0.886" (22.50mm) | 1.378" Dia (35.00mm) | 1.654" (42.00mm) | - | Through Hole, Press-Fit | |
|
MAL213217222E3CAP ALUM 2200UF 40V AXIAL TH |
0 |
|
Datasheet |
132 ALL-DIN | Bulk | Active | 2200 µF | -10%, +50% | 40 V | 70mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 1.9 A @ 100 Hz | - | - | - | 0.827" Dia x 1.496" L (21.00mm x 38.00mm) | - | - | Through Hole |
